– 72 –
REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
KV-PF14DK7/PF14L70/PF14M40/PF14M70
KV-PF14P10/PF14P70/PF14Q70
RM-952
A
R584 1-216-073-00 RES,CHIP 10K 5% 1/10W
R585 1-249-391-11 CARBON 6.8 5% 1/4W F
R590 1-215-465-00 METAL 68K 1% 1/4W
R591 1-260-288-11 CARBON 0.47 5% 1/2W F
R593 1-260-288-11 CARBON 0.47 5% 1/2W F
R594 1-260-288-11 CARBON 0.47 5% 1/2W F
R596 1-215-922-11 METAL OXIDE 6.8K 5% 3W F
R597 1-247-750-11 CARBON 680 5% 1/2W F
R598 1-249-438-11 CARBON 56K 5% 1/4W
R599 1-249-389-11 CARBON 4.7 5% 1/4W
R600 1-249-438-11 CARBON 56K 5% 1/4W
R601 1-249-418-11 CARBON 1.2K 5% 1/4W F
R602 1-249-389-11 CARBON 4.7 5% 1/4W F
R603 1-215-485-00 METAL 470K 1% 1/4W
R605 1-215-906-11 METAL OXIDE 15 5% 3W F
R607 1-249-425-11 CARBON 4.7K 5% 1/4W
R608 1-240-205-91 CARBON 22M 5% 1/2W
R609 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R610 1-216-073-00 RES,CHIP 10K 5% 1/10W
R611 1-216-089-91 RES,CHIP 47K 5% 1/10W
R612 1-216-045-00 RES,CHIP 680 5% 1/10W
R614 1-216-041-00 RES,CHIP 470 5% 1/10W
R615 1-216-353-00 METAL OXIDE 2.2 5% 1W F
R616 1-260-302-51 CARBON 6.8 5% 1/2W F
R617 1-247-791-91 CARBON 22 5% 1/4W
R618 1-215-906-11 METAL OXIDE 15 5% 3W F
R619 1-260-128-11 CARBON 270K 5% 1/2W
R620 1-215-915-11 METAL OXIDE 470 5% 3W F
R622 1-216-400-11 METAL OXIDE 8.2 5% 3W F
R625 1-202-961-11 CEMENTED 1.8 5% 10W
R628 1-202-961-11 CEMENTED 1.8 5% 10W
R632 1-202-933-61 FUSIBLE 0.1 10% 1/2W F
R634 ! 1-218-265-11 METAL 8.2M 5% 1W
R636 1-215-924-00 METAL OXIDE 15K 5% 3W F
R639 1-216-363-00 METAL OXIDE 0.33 5% 2W F
R640 1-249-415-11 CARBON 680 5% 1/4W
R641 1-216-362-11 METAL OXIDE 0.27 5% 2W F
R642 1-249-419-11 CARBON 1.5K 5% 1/4W
R643 1-247-843-11 CARBON 3.3K 5% 1/4W
R644 1-249-419-11 CARBON 1.5K 5% 1/4W
R646 1-215-924-00 METAL OXIDE 15K 5% 3W F
R647 1-249-401-11 CARBON 47 5% 1/4W
R648 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R649 1-249-417-11 CARBON 1K 5% 1/4W
R650 1-215-882-00 METAL OXIDE 22 5% 2W F
R652 1-215-900-11 METAL OXIDE 22K 5% 2W F
R653 1-215-873-00 METAL OXIDE 4.7K 5% 1W F
R657 1-260-127-11 CARBON 220K 5% 1/2W
R659 1-216-049-91 RES,CHIP 1K 5% 1/10W
R660 1-216-073-00 RES,CHIP 10K 5% 1/10W
R661 1-215-873-00 METAL OXIDE 4.7K 5% 1W F
R662 1-216-295-91 SHORT 0
R680 1-216-311-00 RES,CHIP 6.8 5% 1/10W
R901 1-249-411-11 CARBON 330 5% 1/4W
R903 1-216-022-00 RES,CHIP 75 5% 1/10W
R904 1-216-033-00 RES,CHIP 220 5% 1/10W
R905 1-216-113-00 RES,CHIP 470K 5% 1/10W
R906 1-216-077-91 RES,CHIP 15K 5% 1/10W
R909 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R910 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R911 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R912 1-216-041-00 RES,CHIP 470 5% 1/10W
R913 1-216-049-91 RES,CHIP 1K 5% 1/10W
R914 1-216-055-00 RES,CHIP 1.8K 5% 1/10W
R915 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R916 1-216-017-91 RES,CHIP 47 5% 1/10W
R917 1-216-041-00 RES,CHIP 470 5% 1/10W
R918 1-216-041-00 RES,CHIP 470 5% 1/10W
<RELAY>
RY601 ! 1-755-299-11 RELAY
<SWITCH>
S502 1-572-707-11 SWITCH, LEVER
S600 ! 1-571-433-21 SWITCH, PUSH (AC POWER)
S901 1-692-431-21 SWITCH, TACTILE
S902 1-692-431-21 SWITCH, TACTILE
S903 1-692-431-21 SWITCH, TACTILE
S904 1-692-431-21 SWITCH, TACTILE
S905 1-692-431-21 SWITCH, TACTILE
S906 1-692-431-21 SWITCH, TACTILE
S907 1-692-431-21 SWITCH, TACTILE
<TRANSFORMER>
T501 1-437-195-11 TRANSFORMER, HORIZONTAL DRIVE
T503 ! 1-453-313-11 FBT ASSY NX-1912//M3A4
T601 1-424-682-11 TRANSFORMER, LINE FILTER
T603 ! 1-433-512-41 TRANSFORMER, CONVERTER (SRT)
T604 ! 1-431-852-11 TRANSFORMER, CONVERTER (SRT)
<THERMISTOR>
THP600 1-810-961-11 THERMISTOR, POSITIVE
<TUNER>
TU101 8-598-447-10 TUNER, FSS BTF-LG411 (KV-PF14P10/PF14Q70/
PF14P70/PF14L70)
TU101 8-598-449-01 TUNER, FSS BTF-LG433 (except (KV-PF14P10/
PF14Q70/PF14P70/PF14L70)
<CRYSTAL>
X001 1-579-125-11 VIBRATOR, CERAMIC
X301 1-781-134-21 VIBRATOR, CRYSTAL
X302 1-781-132-21 VIBRATOR, CRYSTAL (except KV-14DK7/PF14Q70)
***************************************************************
* A-1331-968-A C3 BOARD MOUNTED
********************
4-382-854-11 SCREW (M3X10), P, SW (+)
C3
