– 73 –
REF. NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF. NO. PART NO. DESCRIPTION REMARK
KV-PF14DK7/PF14L70/PF14M40/PF14M70
KV-PF14P10/PF14P70/PF14Q70
RM-952
<CAPACITOR>
C701 1-162-114-00 CERAMIC 0.0047MF 2KV
C702 1-102-074-00 CERAMIC 0.001MF 10% 50V
C703 1-107-651-11 ELECT 4.7MF 20% 250V
C704 1-130-202-00 FILM 0.022MF 5% 400V
C708 1-102-114-00 CERAMIC 470PF 10% 50V
C709 1-102-114-00 CERAMIC 470PF 10% 50V
C710 1-102-114-00 CERAMIC 470PF 10% 50V
C712 1-102-116-00 CERAMIC 680PF 10% 50V
C713 1-102-117-00 CERAMIC 820PF 10% 50V
C714 1-102-116-00 CERAMIC 680PF 10% 50V
C716 1-126-933-11 ELECT 100MF 20% 16V
C717 1-102-106-00 CERAMIC 100PF 10% 50V
C718 1-126-933-11 ELECT 100MF 20% 16V
C719 1-102-116-00 CERAMIC 680PF 10% 50V
C736 1-102-114-00 CERAMIC 470PF 10% 50V
C737 1-102-114-00 CERAMIC 470PF 10% 50V
C746 1-102-114-00 CERAMIC 470PF 10% 50V
<CONNECTOR>
CN701 1-508-765-00 PIN, CONNECTOR (5MM PITCH) 3P
CN702 1-695-915-11 TAB (CONTACT)
CN703 * 1-564-509-11 PLUG, CONNECTOR 6P
CN704 1-695-915-11 TAB (CONTACT)
CN706 1-695-915-11 TAB (CONTACT)
<DIODE>
D701 8-719-911-19 DIODE 1SS119-25
D702 8-719-911-19 DIODE 1SS119-25
D703 8-719-911-19 DIODE 1SS119-25
D707 8-719-911-19 DIODE 1SS119-25
D708 8-719-911-19 DIODE 1SS119-25
D709 8-719-911-19 DIODE 1SS119-25
D710 8-719-911-19 DIODE 1SS119-25
D711 8-719-911-19 DIODE 1SS119-25
D712 8-719-911-19 DIODE 1SS119-25
D716 8-719-911-19 DIODE 1SS119-25
D717 8-719-121-26 DIODE RD9.1ESL2
<JACK>
J701 ! 1-540-071-22 SOCKET, CRT
<COIL>
L701 1-410-667-31 INDUCTOR 22UH
L706 1-408-619-31 INDUCTOR 220UH
<TRANSISTOR>
Q704 8-729-326-11 TRANSISTOR 2SC2611
Q705 8-729-326-11 TRANSISTOR 2SC2611
Q706 8-729-326-11 TRANSISTOR 2SC2611
Q707 8-729-200-17 TRANSISTOR 2SA1091-O
Q708 8-729-200-17 TRANSISTOR 2SA1091-O
C3
Q709 8-729-200-17 TRANSISTOR 2SA1091-O
Q710 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q711 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q712 8-729-119-78 TRANSISTOR 2SC2785-HFE
<RESISTOR>
R703 1-249-496-11 CARBON 100K 5% 1/2W
R705 1-216-376-00 METAL OXIDE 3.9 5% 2W F
R708 1-216-377-11 METAL OXIDE 4.7 5% 2W F
R710 1-216-486-00 METAL OXIDE 8.2K 5% 3W F
R711 1-260-101-11 CARBON 1.5K 5% 1/2W
R712 1-216-486-00 METAL OXIDE 8.2K 5% 3W F
R713 1-260-101-11 CARBON 1.5K 5% 1/2W
R714 1-216-486-00 METAL OXIDE 8.2K 5% 3W F
R715 1-260-101-11 CARBON 1.5K 5% 1/2W
R719 1-215-471-00 METAL 120K 1% 1/4W
R720 1-247-704-11 CARBON 220 5% 1/4W F
R721 1-215-477-00 METAL 220K 1% 1/4W
R722 1-247-704-11 CARBON 220 5% 1/4W F
R723 1-215-479-00 METAL 270K 1% 1/4W
R724 1-247-704-11 CARBON 220 5% 1/4W F
R725 1-249-424-11 CARBON 3.9K 5% 1/4W
R726 1-249-424-11 CARBON 3.9K 5% 1/4W
R727 1-249-424-11 CARBON 3.9K 5% 1/4W
R728 1-249-408-11 CARBON 180 5% 1/4W
R729 1-249-408-11 CARBON 180 5% 1/4W
R730 1-249-408-11 CARBON 180 5% 1/4W
R731 1-247-791-91 CARBON 22 5% 1/4W
R732 1-247-791-91 CARBON 22 5% 1/4W
R733 1-247-791-91 CARBON 22 5% 1/4W
R734 1-247-739-11 CARBON 100 5% 1/2W
R738 1-247-807-31 CARBON 100 5% 1/4W
R739 1-247-807-31 CARBON 100 5% 1/4W
R740 1-247-807-31 CARBON 100 5% 1/4W
<VARIABLE RESISTOR>
RV702 1-241-656-11 RES, ADJ, METAL FILM 110M
**************************************************************
* A-1241-401-A F BOARD MOUNTED
*******************
1-533-223-11 CLIP, FUSE
* 4-374-846-01 COVER, CAPACITOR, CAP TYPE
<CAPACITOR>
C654 ! 1-117-703-11 CERAMIC 0.0047MF 99% 250V
C4602 ! 1-104-708-11 FILM 0.47MF 20% 250V
F
