– 74 –
REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
KV-PF14DK7/PF14L70/PF14M40/PF14M70
KV-PF14P10/PF14P70/PF14Q70
RM-952
F
<CONNECTOR>
CN4601* 1-580-843-11 PIN, CONNECTOR (POWER)
CN4602* 1-580-843-11 PIN, CONNECTOR (POWER)
CN4603 1-695-915-11 TAB (CONTACT)
<FUSE>
F4601 ! 1-532-237-00 FUSE, TIME-LAG (BET) 3.15A/250V
<RESISTOR>
R4601 ! 1-202-719-00 SOLID 1M 10% 1/2W
<TRANSFORMER>
T4601 1-424-682-11 TRANSFORMER, LINE FILTER
<VARISTOR>
VDR461 1-801-073-31 VARISTOR TNR14V471K660
***************************************************************
MISCELLANEOUS
*****************
1-417-151-21 MATCHING TRANSFORMER, ANTENNA
! 1-419-185-11 COIL, DEGAUSSING
1-452-094-00 CIRCULAR DISC MAGNET B
1-452-032-00 MAGNET,DISC
1-501-372-81 ANTENNA, TELESCOPIC
1-505-547-11 SPEAKER (5X9CM)
! 1-574-062-11 CORD, POWER (WITH CONNECTOR) 2.5A/250V
8-451-401-11 DEFLECTION YOKE (Y14RSA-S)
! 8-735-570-05 PICTURE TUBE (A34LRG70X)
**************************************************************
ACCESSORIES AND PACKING MATERIALS
***************************************
1-417-151-21 MATCHING TRANSFORMER, ANTENNA
3-867-184-12 MANUAL,INSTRUCTION
1-501-372-81 ANTENNA, TELESCOPIC
* 4-377-015-01 BAG, PROTECTION
* 4-070-925-01 INDIVIDUAL CARTON
* 4-070-926-01 CUSHION(UPPER)(ASS’Y)
* 4-070-929-01 CUSHION(LOWER)(ASS’Y)
***************************************************************
REMOTE COMMANDER
**********************
1-418-163-11 REMOTE COMMANDER (RM-952)
9-939-697-01 BATTERY COVER, REMOTE COMMANDER
