ā 70 ā
REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
KV-PF14DK7/PF14L70/PF14M40/PF14M70
KV-PF14P10/PF14P70/PF14Q70
RM-952
A
<TRANSISTOR>
Q002 8-729-230-49 TRANSISTOR 2SC2712-YG
Q003 8-729-424-08 TRANSISTOR UN2111
Q004 8-729-421-22 TRANSISTOR UN2211
Q101 8-729-230-49 TRANSISTOR 2SC2712-YG
Q201 8-729-424-67 TRANSISTOR UN2216
Q203 8-729-421-19 TRANSISTOR UN2213
Q204 8-729-216-22 TRANSISTOR 2SA1162-G
Q206 8-729-421-19 TRANSISTOR UN2213
Q207 8-729-421-19 TRANSISTOR UN2213
Q301 8-729-216-22 TRANSISTOR 2SA1162-G
Q302 8-729-230-49 TRANSISTOR 2SC2712-YG
Q303 8-729-216-22 TRANSISTOR 2SA1162-G
Q305 8-729-216-22 TRANSISTOR 2SA1162-G
Q306 8-729-216-22 TRANSISTOR 2SA1162-G
Q307 8-729-230-49 TRANSISTOR 2SC2712-YG
Q308 8-729-216-22 TRANSISTOR 2SA1162-G
Q312 8-729-216-22 TRANSISTOR 2SA1162-G
Q313 8-729-230-49 TRANSISTOR 2SC2712-YG
Q315 8-729-421-19 TRANSISTOR UN2213
Q401 8-729-424-67 TRANSISTOR UN2216
Q404 8-729-216-22 TRANSISTOR 2SA1162-G
Q503 8-729-230-49 TRANSISTOR 2SC2712-YG
Q505 8-729-931-45 TRANSISTOR IRF614
Q506 8-729-140-96 TRANSISTOR 2SD774-34
Q507 8-729-216-22 TRANSISTOR 2SA1162-G
Q509 8-729-230-49 TRANSISTOR 2SC2712-YG
Q511 8-729-016-32 TRANSISTOR 2SC4927-01
Q604 8-729-200-17 TRANSISTOR 2SA1091-O
Q605 8-729-044-30 TRANSISTOR 2SK2845-LB102
Q606 8-729-230-49 TRANSISTOR 2SC2712-YG
Q607 8-729-922-37 TRANSISTOR 2SD2144S-UVW
Q608 8-729-230-49 TRANSISTOR 2SC2712-YG
Q901 8-729-421-19 TRANSISTOR UN2213
Q902 8-729-421-19 TRANSISTOR UN2213
<RESISTOR>
R001 1-414-233-22 INDUCTOR CHIP 0UH
R002 1-216-025-91 RES,CHIP 100 5% 1/10W
R003 1-216-073-00 RES,CHIP 10K 5% 1/10W
R004 1-216-025-91 RES,CHIP 100 5% 1/10W
R005 1-216-025-91 RES,CHIP 100 5% 1/10W
R007 1-216-295-91 SHORT 0
R008 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R010 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R011 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R012 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R013 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R014 1-216-025-91 RES,CHIP 100 5% 1/10W
R015 1-216-025-91 RES,CHIP 100 5% 1/10W
R017 1-216-049-91 RES,CHIP 1K 5% 1/10W
R018 1-216-033-00 RES,CHIP 220 5% 1/10W
R019 1-216-073-00 RES,CHIP 10K 5% 1/10W
R021 1-216-073-00 RES,CHIP 10K 5% 1/10W
R022 1-216-033-00 RES,CHIP 220 5% 1/10W
R024 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R025 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R026 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R027 1-216-073-00 RES,CHIP 10K 5% 1/10W
R029 1-216-049-91 RES,CHIP 1K 5% 1/10W
R031 1-216-049-91 RES,CHIP 1K 5% 1/10W
R035 1-216-025-91 RES,CHIP 100 5% 1/10W
R036 1-216-025-91 RES,CHIP 100 5% 1/10W
R037 1-216-025-91 RES,CHIP 100 5% 1/10W
R040 1-216-025-91 RES,CHIP 100 5% 1/10W
R041 1-216-025-91 RES,CHIP 100 5% 1/10W
R042 1-216-295-91 SHORT 0
R043 1-216-049-91 RES,CHIP 1K 5% 1/10W
R044 1-216-025-91 RES,CHIP 100 5% 1/10W
R045 1-414-233-22 INDUCTOR CHIP 0UH
R046 1-216-049-91 RES,CHIP 1K 5% 1/10W
R047 1-414-233-22 INDUCTOR CHIP 0UH
R048 1-216-073-00 RES,CHIP 10K 5% 1/10W
R050 1-216-073-00 RES,CHIP 10K 5% 1/10W
R053 1-216-049-91 RES,CHIP 1K 5% 1/10W
R055 1-216-073-00 RES,CHIP 10K 5% 1/10W
R056 1-216-073-00 RES,CHIP 10K 5% 1/10W
R061 1-216-033-00 RES,CHIP 220 5% 1/10W
R062 1-216-041-00 RES,CHIP 470 5% 1/10W
R063 1-216-037-00 RES,CHIP 330 5% 1/10W
R064 1-216-037-00 RES,CHIP 330 5% 1/10W
R065 1-216-037-00 RES,CHIP 330 5% 1/10W
R066 1-216-049-91 RES,CHIP 1K 5% 1/10W
R067 1-216-049-91 RES,CHIP 1K 5% 1/10W
R105 1-216-295-91 SHORT 0
R109 1-216-041-00 RES,CHIP 470 5% 1/10W
R111 1-216-025-91 RES,CHIP 100 5% 1/10W
R112 1-216-025-91 RES,CHIP 100 5% 1/10W
R113 1-216-047-91 RES,CHIP 820 5% 1/10W
R202 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R203 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R204 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R208 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R210 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
R211 1-216-043-91 RES,CHIP 560 5% 1/10W
R212 1-216-031-00 RES,CHIP 180 5% 1/10W
R213 1-216-073-00 RES,CHIP 10K 5% 1/10W
R214 1-216-073-00 RES,CHIP 10K 5% 1/10W
R215 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R216 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R217 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R218 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R219 1-216-025-91 RES,CHIP 100 5% 1/10W
R220 1-216-025-91 RES,CHIP 100 5% 1/10W
R221 1-216-295-91 SHORT 0
R225 1-216-033-00 RES,CHIP 220 5% 1/10W
R226 1-216-033-00 RES,CHIP 220 5% 1/10W
R227 1-216-033-00 RES,CHIP 220 5% 1/10W
R229 1-216-073-00 RES,CHIP 10K 5% 1/10W
R231 1-216-295-91 SHORT 0
R234 1-249-389-11 CARBON 4.7 5% 1/4W
R235 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R236 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R237 1-216-308-00 RES,CHIP 4.7 5% 1/10W
R301 1-216-073-00 RES,CHIP 10K 5% 1/10W
