– 2 –
KV-PF21N70/PF51P40/PF21P70/PF21Q40
RM-915 RM-952 RM-952 RM-952
KV-PF21Q70/PF21M70/PF21DK7
RM-952 RM-952 RM-952
SPECIFICATIONS
(except KV-PF21N70)
CAUTION
SHORT CIRCUIT THE ANODE OF THE PICTURE TUBE AND
THE ANODE CAP TO THE METAL CHASSIS, CRT SHIELD, OR
CARBON PAINTED ON THE CRT, AFTER REMOVING THE
ANODE.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY SHADING AND MARK ! ON THE
SCHEMATIC DIAGRAMS, EXPLODED VIEWS AND IN THE PARTS
LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE
COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS
APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS
PUBLISHED BY SONY. CIRCUIT ADJUSTMENTS THAT ARE
CRITICAL TO SAFE OPERATION ARE IDENTIFIED IN THIS
MANUAL. FOLLOW THESE PROCEDURES WHENEVER CRITICAL
COMPONENTS ARE REPLACED OR IMPROPER OPERATION IS
SUSPECTED.
Note
Power requirements 110-240 V AC, 50/60 Hz
Power consumption (W) Indicated on the rear of the TV
Television system B/G, I, D/K, M KV-PF21M70
B/G, D/K KV-PF21DK7
B/G KV-PF21P70/PF21Q70
KV-PF21Q40/PF21P40
Color system PAL, PAL60, SECAM, NTSC4.43, NTSC3.58 KV-PF21M70
PAL, PAL60, NTSC4.43, NTSC3.58 (AV IN) KV-PF21P70/PF21P40
PAL, PAL60, SECAM, NTSC4.43 KV-PF21Q70/PF21Q40
KV-PF21DK7
Channel coverage
B/G VHF : E2 to E12/ UHF : E21 to E69/
CATV : S01 to S03, S1 to S41
I UHF : B21 to B68/ CATV : S01 to S03, S1 to S41 KV-PF21M70 only
D/K VHF : C1 to C12, R1 to R12/ UHF : C13 to C57, R21 to R60
CATV: S01 to S03, S1 to S41, Z1 to Z39 KV-PF21M70/PF21DK7
M VHF : A2 to A3/ UHF : A14 to A79/
CATV : A-8 to A-2, A to W+4, W+6 to W+84 KV-PF21M70 only
˘ (Antenna) 75-ohm external terinal
Audio output 3W
Number of terminal
(Video) Input : 2 Output : 1 Phono jacks; 1 Vp-p, 75 ohms
(Audio) Input : 2 Output : 1 Phono jacks; 500 mVrms
(Earphone) Output : 1 Minijack
Picture tube 21 inch
Tube size (cm) 54 Measured diagonally
Screen size (cm) 51 Measured diagonally
Dimension (w/h/d, mm) 490 x 458 x 487
Mass (kg) 25
Design and specifications are subject to change without notice.
