– 81 –
REF. NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF. NO. PART NO. DESCRIPTION REMARK
KV-PF21N70/PF51P40/PF21P70/PF21Q40
RM-915 RM-952 RM-952 RM-952
KV-PF21Q70/PF21M70/PF21DK7
RM-952 RM-952 RM-952
C613 1-117-752-11 ELECT(BLOCK) 330MF 20% 450V
C614 1-126-964-11 ELECT 10MF 20% 50V
C616 1-130-202-00 FILM 0.022MF 10% 400V
C617 1-107-792-11 CERAMIC 100PF 5% 1KV
C618 1-125-893-11 FILM 680PF 3% 1.5KV
C619 ! 1-119-886-51 CERAMIC 470PF 10% 250V
C620 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C621 1-102-114-00 CERAMIC 470PF 10% 50V
C622 1-102-119-00 CERAMIC 0.0015MF 10% 50V
(except KV-PF21M70)
C623 1-104-665-11 ELECT 100MF 20% 25V
C624 1-125-772-91 CERAMIC 1500PF 10% 2KV
(except KV-PF21M70)
C627 1-102-002-00 CERAMIC 680PF 10% 500V
C628 1-126-942-61 ELECT 1000MF 20% 25V
C629 1-126-964-11 ELECT 10MF 20% 50V
C630 1-123-024-21 ELECT 33MF 160V
C633 1-104-999-11 MYLAR 0.1MF 10% 200V
C634 1-126-933-11 ELECT 100MF 20% 16V
C635 1-104-665-11 ELECT 100MF 20% 10V
C636 1-104-760-11 CERAMIC CHIP 0.047MF 10% 50V
C639 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C640 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C641 1-102-002-00 CERAMIC 680PF 10% 500V
C642 1-126-943-11 ELECT 2200MF 20% 25V
C643 1-104-665-11 ELECT 100MF 20% 10V
C644 1-104-331-11 CERAMIC 0.0022MF 10% 1KV
C645 1-137-605-11 FILM 0.01MF 10% 250V
C646 1-107-679-91 ELECT 10MF 20% 450V
C647 1-163-275-11 CERAMIC CHIP 0.001MF 5% 50V
C649 1-126-940-11 ELECT 330MF 20% 25V
C650 1-163-275-11 CERAMIC CHIP 0.001MF 5% 50V
C651 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C652 1-126-965-11 ELECT 22MF 20% 50V
C653 1-104-664-11 ELECT 47MF 20% 25V
C657 1-101-821-00 CERAMIC 0.0022MF 500V
C658 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C901 1-136-153-00 FILM 0.01MF 5% 50V
C905 1-126-963-11 ELECT 4.7MF 20% 50V
C906 1-164-346-11 CERAMIC CHIP 1MF 16V
C907 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C910 1-126-967-11 ELECT 47MF 20% 50V
C911 1-126-967-11 ELECT 47MF 20% 50V
C912 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C913 1-104-665-11 ELECT 100MF 20% 10V
C914 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
<CONNECTOR>
CN104 1-695-915-11 TAB (CONTACT)
CN202 * 1-785-608-11 PIN, CONNECTOR 4P
CN203 * 1-564-506-11 PLUG, CONNECTOR 3P
CN204 * 1-564-506-11 PLUG, CONNECTOR 3P
CN305 * 1-564-509-11 PLUG, CONNECTOR 6P
CN505 1-508-765-00 PIN, CONNECTOR (5MM PITCH) 3P
CN506 4-352-844-01 PIN, LEAD, COATING
CN601 * 1-580-843-11 PIN, CONNECTOR (POWER)
CN602 * 1-508-786-00 PIN, CONNECTOR (5MM PITCH) 2P
CN604 * 1-573-963-11 PIN, CONNECTOR (PC BOARD) 3P
CN901 * 1-564-506-11 PLUG, CONNECTOR 3P
<DIODE>
D001 8-719-988-61 DIODE 1SS355TE-17
D005 8-719-988-61 DIODE 1SS355TE-17
D006 8-719-988-61 DIODE 1SS355TE-17
D203 8-719-914-42 DIODE DA204K
D300 1-216-295-91 SHORT 0
D301 8-719-988-61 DIODE 1SS355TE-17
D306 8-719-988-61 DIODE 1SS355TE-17
D307 8-719-988-61 DIODE 1SS355TE-17
D308 8-719-988-61 DIODE 1SS355TE-17
D309 8-719-069-54 DIODE UDZS-TE17-5.1B
D311 8-719-988-61 DIODE 1SS355TE-17
D312 8-719-988-61 DIODE 1SS355TE-17
D313 8-719-988-61 DIODE 1SS355TE-17
D314 8-719-988-61 DIODE 1SS355TE-17
D315 8-719-988-61 DIODE 1SS355TE-17
D316 8-719-069-57 DIODE UDZS-TE17-6.8B
D320 8-719-069-60 DIODE UDZS-TE17-9.1B
D321 8-719-069-60 DIODE UDZS-TE17-9.1B
D402 8-719-069-60 DIODE UDZS-TE17-9.1B
D403 8-719-069-60 DIODE UDZS-TE17-9.1B
D405 8-719-069-60 DIODE UDZS-TE17-9.1B
D406 8-719-069-60 DIODE UDZS-TE17-9.1B
D504 8-719-302-43 DIODE EL1Z
D505 8-719-988-61 DIODE 1SS355TE-17
D506 8-719-911-19 DIODE 1SS119-25
D507 8-719-988-61 DIODE 1SS355TE-17
D508 8-719-988-61 DIODE 1SS355TE-17
D509 1-216-073-00 RES,CHIP 10K 5% 1/10W
D510 8-719-988-61 DIODE 1SS355TE-17
D511 8-719-988-61 DIODE 1SS355TE-17
D512 8-719-988-61 DIODE 1SS355TE-17
D513 8-719-908-03 DIODE GP08D
D517 8-719-312-71 DIODE RS3FS
D518 8-719-900-26 DIODE ERD29-08J
D521 8-719-302-06 DIODE EU2A
D521 8-719-302-43 DIODE EL1Z
D522 8-719-302-43 DIODE EL1Z
D523 8-719-302-43 DIODE EL1Z
D527 8-719-908-03 DIODE GP08D
D528 8-719-908-03 DIODE GP08D
D531 8-719-988-61 DIODE 1SS355TE-17
D532 8-719-988-61 DIODE 1SS355TE-17
D534 1-216-295-91 SHORT 0
D602 8-719-911-19 DIODE 1SS119-25
D603 8-719-150-92 DIODE RD33EB3T
D604 8-719-028-72 DIODE RGP02-17EL-6433
D605 8-719-510-53 DIODE D4SB60L
D606 8-719-108-18 THYRISTOR 5P6M
D607 8-719-073-01 DIODE MA111-(K8).S0
D608 8-719-110-53 DIODE RD20ESB2
