– 84 –
REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
KV-PF21N70/PF51P40/PF21P70/PF21Q40
RM-915 RM-952 RM-952 RM-952
KV-PF21Q70/PF21M70/PF21DK7
RM-952 RM-952 RM-952
R318 1-216-051-00 RES,CHIP 1.2K 5% 1/10W
R319 1-216-025-91 RES,CHIP 100 5% 1/10W
R320 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R321 1-216-073-00 RES,CHIP 10K 5% 1/10W
R322 1-216-033-00 RES,CHIP 220 5% 1/10W
R331 1-216-295-91 SHORT 0
R332 1-216-033-00 RES,CHIP 220 5% 1/10W
R333 1-216-073-00 RES,CHIP 10K 5% 1/10W
R334 1-216-129-00 RES,CHIP 2.2M 5% 1/10W
R335 1-216-045-00 RES,CHIP 680 5% 1/10W
R338 1-216-033-00 RES,CHIP 220 5% 1/10W
R340 1-216-025-91 RES,CHIP 100 5% 1/10W
R345 1-216-081-00 RES,CHIP 22K 5% 1/10W
R348 1-208-806-11 RES,CHIP 10K 0.50% 1/10W
R349 1-216-073-00 RES,CHIP 10K 5% 1/10W
R350 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R351 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R354 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R355 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R356 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R357 1-216-079-00 RES,CHIP 18K 5% 1/10W
R358 1-216-049-91 RES,CHIP 1K 5% 1/10W
R359 1-216-033-00 RES,CHIP 220 5% 1/10W
R360 1-216-033-00 RES,CHIP 220 5% 1/10W
R361 1-216-073-00 RES,CHIP 10K 5% 1/10W
R362 1-216-075-00 RES,CHIP 12K 5% 1/10W
R363 1-216-079-00 RES,CHIP 18K 5% 1/10W
R364 1-216-295-91 SHORT 0
R365 1-216-033-00 RES,CHIP 220 5% 1/10W
R366 1-216-073-00 RES,CHIP 10K 5% 1/10W
R367 1-216-073-00 RES,CHIP 10K 5% 1/10W
R370 1-216-033-00 RES,CHIP 220 5% 1/10W
R376 1-216-081-00 RES,CHIP 22K 5% 1/10W
R377 1-216-121-91 RES,CHIP 1M 5% 1/10W
R378 1-216-031-00 RES,CHIP 180 5% 1/10W
R404 1-216-073-00 RES,CHIP 10K 5% 1/10W
R405 1-216-049-91 RES,CHIP 1K 5% 1/10W
R406 1-216-073-00 RES,CHIP 10K 5% 1/10W
R408 1-216-049-91 RES,CHIP 1K 5% 1/10W
R411 1-216-113-00 RES,CHIP 470K 5% 1/10W
R412 1-216-041-00 RES,CHIP 470 5% 1/10W
R413 1-216-021-00 RES,CHIP 68 5% 1/10W
R414 1-216-113-00 RES,CHIP 470K 5% 1/10W
R417 1-216-077-91 RES,CHIP 15K 5% 1/10W
R418 1-216-113-00 RES,CHIP 470K 5% 1/10W
R419 1-216-022-00 RES,CHIP 75 5% 1/10W
R426 1-216-033-00 RES,CHIP 220 5% 1/10W
R505 1-216-099-00 RES,CHIP 120K 5% 1/10W
R506 1-216-085-00 RES,CHIP 33K 5% 1/10W
R507 1-249-389-11 CARBON 4.7 5% 1/4W F
R508 1-215-910-00 METAL OXIDE 68 5% 3W F
R509 1-215-911-11 METAL OXIDE 100 5% 3W F
R510 1-215-885-00 METAL OXIDE 68 5% 2W F
R511 1-215-911-11 METAL OXIDE 100 5% 3W F
R516 1-216-081-00 RES,CHIP 22K 5% 1/10W
R518 1-247-807-31 CARBON 100 5% 1/4W
R520 1-215-445-00 METAL 10K 1% 1/4W
R063 1-216-037-00 RES,CHIP 330 5% 1/10W
R064 1-216-037-00 RES,CHIP 330 5% 1/10W
R065 1-216-037-00 RES,CHIP 330 5% 1/10W
R066 1-216-049-91 RES,CHIP 1K 5% 1/10W
R067 1-216-049-91 RES,CHIP 1K 5% 1/10W
R105 1-216-295-91 SHORT 0
R109 1-216-041-00 RES,CHIP 470 5% 1/10W
R111 1-216-025-91 RES,CHIP 100 5% 1/10W
R112 1-216-025-91 RES,CHIP 100 5% 1/10W
R113 1-216-047-91 RES,CHIP 820 5% 1/10W
R202 1-216-071-00 RES,CHIP 8.2K 5% 1/10W
R203 1-216-077-91 RES,CHIP 15K 5% 1/10W
R204 1-216-071-00 RES,CHIP 8.2K 5% 1/10W
R208 1-216-073-00 RES,CHIP 10K 5% 1/10W
(except KV-PF21P40)
R208 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
(KV-PF21P40 only)
R210 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
R211 1-216-043-91 RES,CHIP 560 5% 1/10W
R212 1-216-033-00 RES,CHIP 220 5% 1/10W
R213 1-216-073-00 RES,CHIP 10K 5% 1/10W
R214 1-216-073-00 RES,CHIP 10K 5% 1/10W
R215 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R216 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R217 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R218 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R219 1-216-025-91 RES,CHIP 100 5% 1/10W
R220 1-216-025-91 RES,CHIP 100 5% 1/10W
R221 1-216-295-91 SHORT 0
R225 1-216-033-00 RES,CHIP 220 5% 1/10W
R226 1-216-033-00 RES,CHIP 220 5% 1/10W
R227 1-216-033-00 RES,CHIP 220 5% 1/10W
R229 1-216-073-00 RES,CHIP 10K 5% 1/10W
R230 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R231 1-216-295-91 SHORT 0
R234 1-249-389-11 CARBON 4.7 5% 1/4W
R235 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R236 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R237 1-216-308-00 RES,CHIP 4.7 5% 1/10W
R301 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
(except KV-PF21N70/PF21P40)
R301 1-216-073-00 RES,CHIP 10K 5% 1/10W
(KV-PF21N70/PF21P40)
R302 1-216-295-91 SHORT 0
R303 1-216-049-91 RES,CHIP 1K 5% 1/10W
R304 1-216-073-00 RES,CHIP 10K 5% 1/10W
R305 1-216-051-00 RES,CHIP 1.2K 5% 1/10W
R306 1-216-073-00 RES,CHIP 10K 5% 1/10W
R308 1-216-025-91 RES,CHIP 100 5% 1/10W
R309 1-216-025-91 RES,CHIP 100 5% 1/10W
R310 1-216-025-91 RES,CHIP 100 5% 1/10W
R311 1-216-017-91 RES,CHIP 47 5% 1/10W
R312 1-216-041-00 RES,CHIP 470 5% 1/10W
R313 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R314 1-216-045-00 RES,CHIP 680 5% 1/10W
R316 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R317 1-216-077-91 RES,CHIP 15K 5% 1/10W
A
To Next Page
