(3) Screen-corner Convergence
ba
cd
a-d : screen-corner
misconvergence
a
d
c
b
a to d : Permalloy assembly
Fix a Permalloy assy
corresponding to the
misconverged areas
(2) Dynamic Convergence Adjustment
Preparation:
• Before starting this adjustment, adjust the horizontal static
convergence and the vertical static convergence
RB
TLVYCH
B
R
on DY
YCH TLV
