– 17 –
KV-PG14P40/PG14L70/PG14L70/H
RM-952
Adjustment Item Table
Device
Data
Range
Initial
Data
Note for Different Data
Function
Item Adj.
No. Item
00 HSF 3F 24 50/60Hz/RGB50/RGB60 H Shift TDA8375(8A)
01 HSZ 3F 23 50/60Hz/RGB50/RGB60 H Size
02 PAP 3F 21 50/60Hz Pin Amplitude
03 CNP 3F 29 50/60Hz Corner Pin
04 TLT 3F 20 50/60Hz Tilt
05 VSL 3F 20 50/60Hz V Slope
06 VAP 3F 1D 50/60Hz V Amplitude
07 SCR 3F 20 50/60Hz S Correction
08 VSF 3F 20 50/60Hz V Shift
09 VZM 3F 20 Vertical Zoom
0A VSC 3F 50/60Hz Vertical Scroll
0B RDR 3F 25 R Drive
0C GDR 3F 20 G Drive
0D BDR 3F 20 B Drive
0E SBR 7F 4B Sub Brightness
0F PMX 3F 27 TV/Video/Teletext Picture Maximum Data
10 PMI 3F 05 Picture Minimum Data
11 SHU 0F 07 Sub Hue
12 SSH 03 01 TV/Video Sub Sharpness
13 SC1 3F 1F 50/60Hz Sub Color Lower
14 SC2 3F 0B 50/60Hz Sub Color Higher
15 FO 03 00 TV/Video/Teletext 01 Time Constant
16 AGC 3F 06 TV/Video/Teletext AGC Take Over
17 VSW 01 0 TV/Video/Teletext Video Mute Switch
18 FOR 03 00 Forced Field Frequency
19 DL 01 0 De-interlace
1A POC 01 0 Fixed 01 Synchro. Mode
1B COR 01 0 TV/Video/Teletext Noise Coring
1C VPX FF 00 Extra Bits (see below)
1D AIP 7F 40 Invalid
1E CT2 FF Control 2
1F CT3 FF Control 3
20 CT4 0F Control 4
21 CT5 01 Control 5
22 BCO 01 Switch-on Behaviour
23 RBL 01 RGB Blanking
24 YDL 0F PAL/NTSC/SECAM Y-Delay
25 WST FF 15 W/G Stereo Threshold MSP3410D(80)
26 WBT FF EA W/G Bilingual Threshold
27 WLL FF 05 W/G Monaural Threshold
28 ACG 01 01 AGC Switch auto/constant
29 CDB 3F 28 AGC Gain at Constant Mode
2A FGP 7F 1B FM Prescale for B/G, I, D/K
2B FMP 7F 32 FM Prescale for M
2C FMH 7F 36 FM Prescale for HDEV (non-M)
2D FMM 7F 65 FM Prescale for HDEV (M)
2E WGP 7F 2A W/G Prescale
2F NIP 7F 6D NICAM Prescale
30 SCP 7F 3B SCART Input Prescale
31 SCV 7F 2A SCART Output Prescale
32 CRM 01 00 Carrier Muting on/off
33 ACO 01 01 Audio Clock-out on/off
34 WAC 0F 00 W/G Agreement count
35 NFT FF 50 Auto FM Switch Threshold
36 DLG FF 30 W/G Search Delay
37 DLN FF 20 NICAM Search Delay
38 DLS FF 10 Stereo Status Read Delay
39 SMX 7F 73 DFP Volume Maximum
3A ING 0F 00 M System/non-M/Video Inupt Gain TDA7438(88)
3B VOM 3F 01 M System only Volume Output Gain
3C BCS 03 01 Bass Center Shift
3D TCS 03 01 Treble Center Shift
3E TXH FF 2D Horizontal Display Position SAA5264(58)
3F TXV 3F 2A Vertical Display Position
(line offset from V-sync)
40 THD 7F 00 H-sync Active Edge Shift
41 TVD 7F 0F V-sync Active Edge Shift
To Next Page
