– 18 –
KV-PG14P40/PG14L70/PG14L70/H
RM-952
Adjustment Item Table
Device
Data
Range
Initial
Data
Note for Different Data
Function
Item Adj.
No. Item
42 HPL 01 00 00 : Positive, 01 : Negative H-sync Polarity Configuration
43 VPL 01 00 00 : Positive, 01 : Negative V-sync Polarity Configuration
44 FMD 03 02 00 : Auto, 01 : Default, Force Mode
02 : Fastext, 03 : Top mode
45 TBR 0F 08 Set Teletext RGB Brightness
46 NOP 0F 01
National Option Table Configuration
47 TCH 03 01 Twisted Character Set Configuration
48 BKP 3F 00 Picture Data at Blanking OFF Other Control
49 ODL FF 10 Power ON Delay
4A OFR 0F 00 RGB Output Time (STBY OFF)
4B OFM 0F 00 RGB Output Time (AC OFF)
4C OSH 3F 0A OSD H Position
4D TSY 03 00
00 : B/G, 01 : I, 02 : D/K, 03: M
TV System at Auto Preset
4E DKS 01 01 D/K Stereo enable/disable
4F MUT 01 00 Muting on/off at No Sync
50 ABL 01 00 Bright ABL Switch
51 SCM 01 00 SECAM Trap active/inactive
52 FBT 01 01 FBT L/S C/M strict/plain
53 SLS 01 01 Activate SL. OR. IFI Sync
54 SSV 07 02 Space Sound Volume Step Up
55 VPM 7F 28
Timer of Video Processor start up wait
56 OP0 FF 2F Optional Flags 0 (see below)
57 OP1 FF 0F Optional Flags 1 (see below
58 OP2 FF 00 Optional Flags 2 (see below)
NOTE
• Standard data listed on the Adjustment Item Table are reference values, therefore it may be different for each model
and for each mode.
• Note for Different Data Those are the standard data values written on the microprocessor. Therefore, the data values
of the modes and stored respectively in the memory.
In case of a device replacement, adjustment by rewriting the data value is necessary for some items.
To Next Page
