– 19 –
KV-PG14P40/PG14L70/PG14L70/H
RM-952
Item
KV-PG14P40
KV-PG14L70
KV-PG14L70/H
Item
KV-PG14P40
KV-PG14L70
KV-PG14L70/H
ITEM INFORMATION
No. 1E VP1
HCO EHT Tracking Mode 1 = on V and E-W, 0 = only on V 0A(7)
EVG Enable Vertical Guard 1 = enable, 0 = disable 0A(6)
SBL Service Blanking 1 = active, 0 = inactive OB(7)
PRD Over-voltage Protection Detection 1 = enable, 0 = disable OB(6)
HBL RGB Blanking Mode 1 = wide blanking, 0 = normal blanking 02(7)
AKB Black Current Stabilisation 1 = not active, 0 = active 02(6)
MAT PAL-SECAM-/NTSC Matrix 1 = PAL matrix. 0 = adapted to standard 0E(7)
VID Video IdentMode 1 = not for 01-loop, 0 = for 01-loop 09(7)
AV Input 00 = no AV Input model 01 = 1 AV Input model
10 = 2 AV Input model 11 = 2AV Input and RGB input model
AVMUT 1 = AV multi is always muted if no signal input, 0 = not muted always
Other optional bits are effective if set ti 1.
No. 20 VP3
VID
1
1
1
MAT
1
1
1
1 V-Curve
0
0
0
No NICAM
0
0
0
-
0
0
0
HDEV
0
0
0
XTAL SEL 00 = only 4.43 XTAL 01 = only 3.58 XTAL
10 = not used 11 = both 4.43 and 3.58 XTAL
1 V-Curve (for monaural model)
1 = using common volume curve for every mode and every TV system
0 = another volume curve available for video mode and M system
HDEV 1 = High Deviation Mode switch available, 0 = not available
No NICAM 1 = NICAM search is disable in any TV system, 0 = NICAM search operates
Other optional bits are effective if set to 1.
XTAL SEL
No. 1E VP1
M
0
0
0
D/K
0
0
0
I
0
0
0
B/G
1
1
1
AVMUT
0
0
0
AV Input-
0
0
0
Item
KV-PG14P40
KV-PG14L70
KV-PG14L70/H
VID
0
0
0
MATAKBHBLPRD
0
0
0
SBL
0
0
0
EVG
0
0
0
HCO
0
0
0
0
0
0
1
1
1
1
1
1
1
1
1
