Sony TRINITRON KV-PG14L70 - Page 37

– 42 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-PG14P40/PG14L70/PG14L70/H
RM-952
C812 1-117-664-11 FILM 0.27UF 5.00% 250V
C813 1-162-116-00 CERAMIC 680PF 10.00% 2KV
C814 1-117-644-11 FILM 10000PF 3.00% 1.2KV
C852 1-117-661-71 FILM 0.15UF 5.00% 250V
C856 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C857 1-126-964-11 ELECT 10UF 20.00% 50V
C858 1-162-974-11 CERAMIC CHIP 0.01UF 50V
C859 1-162-974-11 CERAMIC CHIP 0.01UF 50V
C860 1-208-834-11 METAL CHIP 150K 0.5% 1/10W
C863 1-216-295-91 SHORT 0
C865 1-126-933-11 ELECT 100UF 20.00% 16V
C866 1-162-974-11 CERAMIC CHIP 0.01UF 50V
C867 1-162-966-11 CERAMIC CHIP 0.0022UF 10.00% 50V
C868 1-162-995-11 CERAMIC CHIP 0.022UF 50V
C869 1-115-339-11 CERAMIC CHIP 0.1UF 10.00% 50V
C870 1-162-960-11 CERAMIC CHIP 220PF 10.00% 50V
C872 1-163-038-91 CERAMIC CHIP 0.1UF 25V
C873 1-162-974-11 CERAMIC CHIP 0.01UF 50V
C874 1-162-974-11 CERAMIC CHIP 0.01UF 50V
C875 1-163-038-91 CERAMIC CHIP 0.1UF 25V
<FILTER>
CF355 1-234-686-21 FILTER, BAND PASS (F5.5C)
<CONNECTOR>
CN003 * 1-508-797-00 PIN, CONNECTOR 4P
CN200 * 1-564-506-11 PLUG, CONNECTOR 3P
CN300 * 1-564-509-11 PLUG, CONNECTOR 6P
CN500 * 1-564-508-11 PLUG, CONNECTOR 5P
CN600 * 1-508-786-00 PIN, CONNECTOR (5MM PITCH) 2P
CN601 * 1-573-963-11 PIN, CONNECTOR (PC BOARD) 3P
CN602 1-580-843-11 PIN, CONNECTOR (POWER)
<TRIMMER>
CT131 1-767-774-22 TRAP, CERAMIC (KV-PG14P40)
CT139 1-767-775-22 TRAP, CERAMIC
CT355 1-795-343-21 TRAP, CERAMIC (T55B)
<DIODE>
D001 8-719-083-18 DIODE SPB-25MVWF
D004 8-719-911-19 1SS119-25
D005 8-719-109-85 RD5.1ESB2
D007 8-719-159-10 RD5.1SB-T2
D009 8-719-159-10 RD5.1SB-T2
D103 8-759-157-40 UPC574J
D104 8-719-914-42 DA204K
D200 8-719-914-42 DA204K
D202 8-719-041-97 MA113-(TX)
D203 8-719-041-97 MA113-(TX)
D304 8-719-063-66 HZS361-TE
D305 8-719-041-97 MA113-(TX)
D306 8-719-109-54 RD2.2ES-B2
D306 8-719-109-54 RD2.2ES-B2
D307 8-719-041-97 MA113-(TX)
D308 8-719-041-97 MA113-(TX)
D309 8-719-069-60 UDZSTE-179.1B
D310 8-719-911-19 1SS119-25
D311 8-719-070-15 NNCD8.2A-T1
D312 8-719-069-60 UDZSTE-179.1B
D314 8-719-908-03 GP08D
D315 8-719-041-97 MA113-(TX)
D318 8-719-041-97 MA113-(TX)
D319 8-719-041-97 MA113-(TX)
D320 8-719-041-97 MA113-(TX)
D321 8-719-041-97 MA113-(TX)
D322 8-719-069-60 UDZSTE-179.1B
D323 8-719-069-60 UDZSTE-179.1B
D324 8-719-069-60 UDZSTE-179.1B
D325 8-719-069-60 UDZSTE-179.1B
D326 8-719-988-61 1SS355TE-17 (KV-PG14L70/PG14L70/H)
D327 8-719-988-61 1SS355TE-17
D329 8-719-109-89 RD5.6ESB2
D330 8-719-109-89 RD5.6ESB2
D400 8-719-041-97 MA113-(TX)
D401 8-719-041-97 MA113-(TX)
D403 8-719-069-60 UDZSTE-179.1B
D404 8-719-069-60 UDZSTE-179.1B
D406 8-719-069-60 UDZSTE-179.1B
D407 8-719-069-60 UDZSTE-179.1B
D408 8-719-069-60 UDZSTE-179.1B
D500 8-719-911-19 1SS119-25
D501 8-719-911-19 1SS119-25
D502 8-719-302-43 EL1Z
D503 8-719-302-43 EL1Z
D504 8-719-302-43 EL1Z
D552 8-719-908-03 GP08D
D553 8-719-109-89 RD5.6ESB2
D600 8-719-030-33 DIODE EG01CV1
D601 8-719-077-77 D3SB60F3
D602 8-719-084-25 DIODE RM2LF-C4
D603 8-719-110-39 RD15ES-B1
D604 8-719-063-70 D1NL20U
D605 8-719-063-70 D1NL20U
D606 8-719-063-70 D1NL20U
D608 8-719-312-10 RU4AM-T3
D609 8-719-510-73 S3L20UF4
D800 8-719-911-19 1SS119-25
D802 8-719-908-03 GP08D
D803 8-719-908-03 GP08D
D804 8-719-081-00 DIODE BY228/A52A/
D805 8-719-069-60 UDZSTE-179.1B
D851 8-719-979-85 EGP20G
D853 8-719-041-97 MA113-(TX)
<CONNECTOR>
DY1 * 1-580-798-11 CONNECTOR PIN (DY) 6P
<FUSE>
F600 ! 1-532-237-11 FUSE, TIME-LAG (BET) 3.15A/250V
<FERRITE BEAD>
FB001 1-410-397-21 FERRITE 1.1UH
FB100 1-239-358-21 FILTER, NOISE
FB602 1-410-397-21 FERRITE 1.1UH
FB603 1-410-397-21 FERRITE 1.1UH
FB800 1-410-397-21 FERRITE 1.1UH
A
