– 43 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-PG14P40/PG14L70/PG14L70/H
RM-952
<IC>
IC001 8-752-925-65 IC CXP85224A-080S
(KV-PG14L70/PG14L70/H)
IC001 8-752-925-64 IC CXP85224A-079S (KV-PG14P40)
IC002 8-759-371-21 MM1319AFBE
IC003 8-759-672-78 M24C08-BN6(A)
IC004 8-742-225-20 IC SBX3081-21
IC203 6-700-036-01 IC AN5279
IC301 6-700-146-01 IC TDA8844/N2 (KV-PG14L70/PG14L70/H)
IC301 6-700-145-01 IC TDA8843/N2 (KV-PG14P40)
IC400 6-700-033-01 IC MM1501XNRE
IC402 8-759-100-96 UPC4558G2
IC551 8-759-835-98 IC AN5522
IC601 8-749-019-43 IC STR-F6706A
IC602 8-749-920-61 SE-135N
IC604 8-759-459-99 PQ09RD11
IC850 8-759-700-07 NJM2903M
IC851 8-759-701-01 NJM2904
<JACK>
J200 1-770-785-12 JACK
J400 1-779-849-11 JACK BLOCK, PIN 4P
J401 1-779-205-11 JACK, PIN 2P
<CHIP CONDUCTOR>
JR001 1-216-295-91 SHORT 0
JR003 1-216-295-91 SHORT 0
JR012 1-216-295-91 SHORT 0
JR013 1-216-295-91 SHORT 0
JR014 1-216-295-91 SHORT 0
JR015 1-216-295-91 SHORT 0
JR017 1-216-295-91 SHORT 0
JR018 1-216-295-91 SHORT 0
JR020 1-216-295-91 SHORT 0
JR035 1-216-295-91 SHORT 0
JR036 1-216-295-91 SHORT 0
JR100 1-216-295-91 SHORT 0
JR202 1-216-295-91 SHORT 0
JR212 1-216-295-91 SHORT 0
JR214 1-216-295-91 SHORT 0
JR300 1-216-295-91 SHORT 0
JR304 1-216-295-91 SHORT 0
<COIL>
L001 1-414-855-31 INDUCTOR 1UH
L002 1-414-184-41 INDUCTOR 15UH
L100 1-414-856-11 INDUCTOR 10UH
L101 1-410-498-11 INDUCTOR 1.2UH
L102 1-410-985-42 INDUCTOR 0.22UH
L103 1-410-987-42 INDUCTOR 0.33UH
L300 1-410-511-11 INDUCTOR 15UH
L305 1-410-510-11 INDUCTOR 12UH
L308 1-410-501-11 INDUCTOR 2.2UH
L310 1-408-608-31 INDUCTOR 27UH
(KV-PG14L70/PG14L70/H)
L400 1-414-855-31 INDUCTOR 1UH
L500 1-408-947-00 INDUCTOR 2.2MH
L600 1-412-533-21 INDUCTOR 47UH
L800 1-406-677-11 INDUCTOR 10MH
L802 1-424-795-11 COIL, HORIZONTAL LINEARITY
L803 1-414-493-41 INDUCTOR 4.7MH
<PHOTO COUPLER>
PH600 ! 8-749-010-64 PC123F2
<TRANSISTOR>
Q001 8-729-421-19 UN2213
Q002 8-729-421-19 UN2213
Q003 8-729-010-25 MSD601-RT1
Q004 8-729-010-25 MSD601-RT1
Q005 8-729-010-25 MSD601-RT1
Q100 8-729-010-25 MSD601-RT1
Q102 8-729-022-54 TRANSISTOR 2SC3779C,D-AA
Q105 8-729-010-25 MSD601-RT1
Q106 8-729-010-25 MSD601-RT1
Q201 8-729-010-25 MSD601-RT1
Q204 8-729-216-22 2SA1162-G
Q205 8-729-421-22 UN2211
Q301 8-729-010-05 MSB709-RT1
Q303 8-729-010-25 MSD601-RT1
Q305 8-729-010-05 MSB709-RT1
Q309 8-729-010-25 MSD601-RT1
Q314 8-729-421-22 UN2211 (KV-PG14L70/PG14L70/H)
Q315 8-729-010-25 MSD601-RT1
Q318 8-729-010-25 MSD601-RT1
Q320 8-729-421-22 UN2211
Q400 8-729-010-05 MSB709-RT1
Q401 8-729-424-67 UN2216
Q404 8-729-010-05 MSB709-RT1
Q405 8-729-010-05 MSB709-RT1
Q406 8-729-010-25 MSD601-RT1
Q407 8-729-010-25 MSD601-RT1
Q500 8-729-200-17 2SA1091-O
Q800 8-729-140-50 2SC3209LK
Q801 8-729-055-74 TRANSISTOR 2SD2624-CA
Q802 8-729-050-48 TRANSISTOR IRF614-005
Q850 8-729-010-25 MSD601-RT1
Q851 8-729-010-05 MSB709-RT1
<RESISTOR>
R001 1-216-071-00 RES-CHIP 8.2K 5% 1/10W
R002 1-216-071-00 RES-CHIP 8.2K 5% 1/10W
R003 1-216-059-00 RES-CHIP 2.7K 5% 1/10W
R004 1-216-059-00 RES-CHIP 2.7K 5% 1/10W
R005 1-216-043-91 RES-CHIP 560 5% 1/10W
R006 1-216-043-91 RES-CHIP 560 5% 1/10W
R007 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R008 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R009 1-216-037-00 RES-CHIP 330 5% 1/10W
R010 1-216-037-00 RES-CHIP 330 5% 1/10W
R011 1-216-295-91 SHORT 0
R012 1-216-049-11 RES-CHIP 1K 5% 1/10W
R013 1-216-041-00 RES-CHIP 470 5% 1/10W
R014 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R015 1-216-025-11 RES-CHIP 100 5% 1/10W
A
To Next Page
