– 45 –
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-PG14P40/PG14L70/PG14L70/H
RM-952
R553 1-249-385-11 CARBON 2.2 5% 1/4W
R554 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R557 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R558 1-216-081-00 RES-CHIP 22K 5% 1/10W
R559 1-216-089-91 RES-CHIP 47K 5% 1/10W
R563 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R564 1-215-865-11 METAL OXIDE 220 5% 1W
R565 1-216-350-11 METAL OXIDE 1.2 5% 1W
R567 1-208-790-11 METAL CHIP 2.2K 0.5% 1/10W
R568 1-215-457-00 METAL 33K 1% 1/4W
R600 1-215-915-11 METAL OXIDE 470 5% 3W
R602 1-205-997-11 CEMENTED 2.2 5% 10W
R605 1-207-615-00 METAL 0.33 10% 2W
R606 1-216-045-00 RES-CHIP 680 5% 1/10W
R608 1-260-129-11 CARBON 330K 5% 1/2W
R609 1-216-097-11 RES-CHIP 100K 5% 1/10W
R610 1-215-926-00 METAL OXIDE 33K 5% 3W
R611 1-216-061-91 RES-CHIP 3.3K 5% 1/10W
R612 1-249-419-11 CARBON 1.5K 5% 1/4W
R614 1-216-397-11 METAL OXIDE 4.7 5% 3W
R615 1-215-877-11 METAL OXIDE 22K 5% 1W
R617 1-216-049-11 RES-CHIP 1K 5% 1/10W
R619 ! 1-240-917-91 METAL 8.2M 5% 1W
R620 1-249-389-11 CARBON 4.7 5% 1/4W
R623 1-216-053-00 RES-CHIP 1.5K 5% 1/10W
R624 1-260-125-11 CARBON 150K 5% 1/2W
R625 1-216-397-11 METAL OXIDE 4.7 5% 3W
R626 1-260-292-11 CARBON 1 5% 1/2W
R628 1-216-295-91 SHORT 0
R800 1-216-049-11 RES-CHIP 1K 5% 1/10W
R801 1-216-081-00 RES-CHIP 22K 5% 1/10W
R802 1-215-919-11 METAL OXIDE 2.2K 5% 3W
R803 1-260-332-51 CARBON 2.2K 5% 1/2W
R806 1-216-295-91 SHORT 0
R808 1-249-421-11 CARBON 2.2K 5% 1/4W
R810 1-215-886-11 METAL OXIDE 100 5% 2W
R811 1-215-911-11 METAL OXIDE 100 5% 3W
R812 1-215-919-11 METAL OXIDE 2.2K 5% 3W
R813 1-216-049-11 RES-CHIP 1K 5% 1/10W
R860 1-216-103-00 RES-CHIP 180K 5% 1/10W
R861 1-216-295-91 SHORT 0
R862 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R863 1-216-073-91 RES-CHIP 10K 5% 1/10W
R864 1-208-794-11 METAL CHIP 3.3K 0.5% 1/10W
R865 1-216-073-91 RES-CHIP 10K 5% 1/10W
R866 1-216-049-11 RES-CHIP 1K 5% 1/10W
R867 1-208-812-11 METAL CHIP 18K 0.5% 1/10W
R868 1-249-393-11 CARBON 10 5% 1/4W
R869 1-249-381-11 CARBON 1 5% 1/4W
R870 1-216-103-00 RES-CHIP 180K 5% 1/10W
R874 1-215-475-00 METAL 180K 1% 1/4W
R878 1-216-049-11 RES-CHIP 1K 5% 1/10W
R879 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R880 1-216-097-11 RES-CHIP 100K 5% 1/10W
R881 1-216-085-91 RES-CHIP 33K 5% 1/10W
R882 1-216-073-91 RES-CHIP 10K 5% 1/10W
R883 1-216-067-00 RES-CHIP 5.6K 5% 1/10W
R884 1-216-089-91 RES-CHIP 47K 5% 1/10W
R885 1-216-073-91 RES-CHIP 10K 5% 1/10W
R886 1-216-295-91 SHORT 0
R887 1-215-477-00 METAL 220K 1% 1/4W
R367 1-216-099-00 RES-CHIP 120K 5% 1/10W
R368 1-216-049-11 RES-CHIP 1K 5% 1/10W
R369 1-216-123-11 RES-CHIP 1.2M 5% 1/10W
R370 1-216-083-00 RES-CHIP 27K 5% 1/10W
R371 1-208-820-11 METAL CHIP 39K 0.5% 1/10W
R374 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R376 1-216-295-91 SHORT 0
R381 1-216-295-91 SHORT 0
R385 1-216-295-91 SHORT 0
R386 1-216-295-91 SHORT 0
R390 1-208-822-11 METAL CHIP 47K 0.5% 1/10W
R391 1-208-822-11 METAL CHIP 47K 0.5% 1/10W
R392 1-216-069-00 RES-CHIP 6.8K 5% 1/10W
R393 1-216-049-11 RES-CHIP 1K 5% 1/10W
R400 1-216-295-91 SHORT 0
R401 1-216-049-11 RES-CHIP 1K 5% 1/10W
R409 1-216-113-00 RES-CHIP 470K 5% 1/10W
R410 1-216-025-11 RES-CHIP 100 5% 1/10W
R411 1-216-049-11 RES-CHIP 1K 5% 1/10W
R412 1-216-049-11 RES-CHIP 1K 5% 1/10W
R413 1-216-113-00 RES-CHIP 470K 5% 1/10W
R414 1-216-049-11 RES-CHIP 1K 5% 1/10W
R415 1-216-073-91 RES-CHIP 10K 5% 1/10W
R416 1-216-073-91 RES-CHIP 10K 5% 1/10W
R417 1-216-021-00 RES-CHIP 68 5% 1/10W
R418 1-216-025-11 RES-CHIP 100 5% 1/10W
R420 1-216-049-11 RES-CHIP 1K 5% 1/10W
R421 1-216-049-11 RES-CHIP 1K 5% 1/10W
R423 1-208-820-11 METAL CHIP 39K 0.5% 1/10W
R424 1-216-091-00 RES-CHIP 56K 5% 1/10W
R425 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R426 1-216-049-11 RES-CHIP 1K 5% 1/10W
R427 1-216-051-00 RES-CHIP 1.2K 5% 1/10W
R428 1-216-041-00 RES-CHIP 470 5% 1/10W
R429 1-216-073-91 RES-CHIP 10K 5% 1/10W
R430 1-216-063-91 RES-CHIP 3.9K 5% 1/10W
R432 1-216-121-11 RES-CHIP 1M 5% 1/10W
R433 1-216-091-00 RES-CHIP 56K 5% 1/10W
R434 1-216-049-11 RES-CHIP 1K 5% 1/10W
R436 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R438 1-216-049-11 RES-CHIP 1K 5% 1/10W
R440 1-216-121-11 RES-CHIP 1M 5% 1/10W
R445 1-216-089-91 RES-CHIP 47K 5% 1/10W
R447 1-216-025-11 RES-CHIP 100 5% 1/10W
R500 1-260-126-81 CARBON 180K 5% 1/2W
(KV-PG14L70/PG14L70/H)
R501 1-249-418-11 CARBON 1.2K 5% 1/4W
R502 1-216-371-00 METAL OXIDE 1.5 5% 2W
R503 1-216-091-00 RES-CHIP 56K 5% 1/10W
R504 1-216-091-00 RES-CHIP 56K 5% 1/10W
R505 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R506 1-260-125-11 CARBON 150K 5% 1/2W
R507 1-260-288-11 CARBON 0.47 5% 1/2W
R508 1-260-288-11 CARBON 0.47 5% 1/2W
R509 1-260-288-11 CARBON 0.47 5% 1/2W
R510 1-260-127-11 CARBON 220K 5% 1/2W
(KV-PG14L70/PG14L70/H)
R511 1-215-463-00 METAL 56K 1% 1/4W
R512 1-215-453-00 METAL 22K 1% 1/4W
R513 1-215-449-00 METAL 15K 1% 1/4W
R514 1-249-421-11 CARBON 2.2K 5% 1/4W
A
