REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
KV-PG14P40/PG14L70/PG14L70/H
RM-952
R888 1-215-477-00 METAL 220K 1% 1/4W
R889 1-208-830-11 METAL CHIP 100K 0.5% 1/10W
<SWITCH>
S001 1-692-431-21 SWITCH, TACTILE
S002 1-692-431-21 SWITCH, TACTILE
S003 1-692-431-21 SWITCH, TACTILE
S004 1-692-431-21 SWITCH, TACTILE
S005 1-692-431-21 SWITCH, TACTILE
S006 1-692-431-31 SWITCH, TACTILE
S600 ! 1-571-433-21 SWITCH, PUSH (AC POWER)
S800 1-572-707-11 SWITCH, LEVER
<#########>
SWF100 1-577-169-12 SAWF
<TRANSFORMER>
T503 ! 1-453-309-21 TRANSFORMER ASSY FLYBACK
(NX-4450//M3A4)
T600 ! 1-424-682-11 TRANSFORMER, LINE FILTER
(KV-PG14L70/PG14L70/H)
T601 ! 1-437-332-11 TRANSFORMER, CONVERTER (SRT)
T800 1-435-374-11 TRANSFORMER, FERRITE (HDT)
<THERMISTOR>
THP600 1-803-744-11 THERMISTOR, POSITIVE
<TUNER>
TU100 8-598-591-00 TUNER, VSS BT-AG402
<VARISTOR>
VDR600 1-803-830-31 VARISTOR (ERZV14D621)
(KV-PG14L70/PG14L70/H)
<CRYSTAL>
X001 1-577-358-21 VIBRATOR, CERAMIC
X300 1-567-505-11 OSCILLATOR, CRYSTAL
X301 1-567-504-11 OSCILLATOR, CRYSTAL
*************************************************************
* A-1332-226-A C BOARD MOUNTED
****************
4-382-854-01 SCREW (M3X8), P, SW (+)
<CAPACITOR>
C701 1-115-350-51 CERAMIC 0.0047UF 2KV
C702 1-102-074-00 CERAMIC 0.001UF 10.00% 50V
C703 1-107-651-11 ELECT 4.7UF 20.00% 250V
C704 1-130-202-00 FILM 0.022UF 5.00% 400V
C708 1-102-114-00 CERAMIC 470PF 10.00% 50V
C709 1-102-114-00 CERAMIC 470PF 10.00% 50V
C710 1-102-114-00 CERAMIC 470PF 10.00% 50V
C712 1-102-116-00 CERAMIC 680PF 10.00% 50V
C713 1-102-117-00 CERAMIC 820PF 10.00% 50V
C714 1-102-116-00 CERAMIC 680PF 10.00% 50V
C716 1-126-933-11 ELECT 100UF 20.00% 16V
C717 1-102-106-00 CERAMIC 100PF 10.00% 50V
C718 1-126-933-11 ELECT 100UF 20.00% 16V
C719 1-102-116-00 CERAMIC 680PF 10.00% 50V
C736 1-102-114-00 CERAMIC 470PF 10.00% 50V
C737 1-102-114-00 CERAMIC 470PF 10.00% 50V
C746 1-102-114-00 CERAMIC 470PF 10.00% 50V
<CONNECTOR>
CN701 * 1-564-508-11 PLUG, CONNECTOR 5P
CN702 1-695-915-11 TAB (CONTACT)
CN703 * 1-564-509-11 PLUG, CONNECTOR 6P
CN704 1-695-915-11 TAB (CONTACT)
<DIODE>
D701 8-719-911-19 1SS119-25
D702 8-719-911-19 1SS119-25
D703 8-719-911-19 1SS119-25
D707 8-719-911-19 1SS119-25
D708 8-719-911-19 1SS119-25
D709 8-719-911-19 1SS119-25
D716 8-719-911-19 1SS119-25
D717 8-719-070-16 NNCD9.1A-T1
<JACK>
J701 ! 1-540-071-22 SOCKET, CRT
<COIL>
L701 1-412-529-11 INDUCTOR 22UH
L706 1-414-191-11 INDUCTOR 150UH
<TRANSISTOR>
Q704 8-729-326-11 2SC2611
Q705 8-729-326-11 2SC2611
Q706 8-729-326-11 2SC2611
Q707 8-729-200-17 2SA1091-O
Q708 8-729-200-17 2SA1091-O
Q709 8-729-200-17 2SA1091-O
Q710 8-729-119-78 2SC2785-HFE
Q711 8-729-119-78 2SC2785-HFE
Q712 8-729-119-78 2SC2785-HFE
<RESISTOR>
R703 1-219-752-11 CARBON 100K 5% 1/2W
R705 1-216-365-00 METAL OXIDE 0.47 5% 2W
R710 1-216-486-00 METAL OXIDE 8.2K 5% 3W
R711 1-260-103-11 CARBON 2.2K 5% 1/2W
R712 1-216-486-00 METAL OXIDE 8.2K 5% 3W
R713 1-260-105-11 CARBON 3.3K 5% 1/2W
R714 1-216-486-00 METAL OXIDE 8.2K 5% 3W
R715 1-260-105-11 CARBON 3.3K 5% 1/2W
