Video signal
Color system NTSC, PAL
Resolution 600 TV lines
Aperture correction 0 dB – +6.0 dB
Frequency response LINE 9.0 MHz (–3 dB)
RGB 10.0 MHz (–3 dB)
Synchronization AFC time constant 1.0 msec.
Picture performance
Overscan 20% overscan of CRT effective
screen area
Normal scan 7% overscan of CRT effective screen
area
Underscan 5% underscan of CRT effective
screen area
Linearity PVM-1353MD
Horizontal: Less than 4% (typical)
Vertical: Less than 4% (typical)
PVM-1953MD
Horizontal: Less than 5% (typical)
Vertical: Less than 5% (typical)
Convergence Central area
0.6 mm (typical) (PVM-1353MD)
0.7 mm (typical) (PVM-1953MD)
Peripheral area
0.8 mm (typical) (PVM-1353MD)
1.3 mm (typical) (PVM-1953MD)
Raster size stability H 1.0%, V 1.5%
High voltage regulation
3.5% (PVM-1353MD)
4.0% (PVM-1953MD)
CRT SMPTE-C phosphor
Color temperature 6500K/5600K/USER (3200K –
10000K, factory setting is 6500K)
Inputs
Y/C IN 4-pin mini DIN connector
See the pin assignment on the
page 14.
VIDEO IN BNC connector 1Vp-p ±6 dB, sync
negative
AUDIO IN phono jack, –5 dBu, more than 47k
ohms
R/R-Y IN, G/Y IN, B/B-Y IN
BNC connector
R, G, B channels 0.7 Vp-p ±6 dB
Sync on green 1 Vp-p Composite sync negative,
75 ohms terminated
R-Y, B-Y channels 0.7 Vp-p ±6 dB
Y channel 1.0 Vp-p ±6 dB
(Standard color bar signal of 75%
chrominance)
EXT SYNC IN BNC connector composite sync
4 Vp-p ±6 dB, negative
0 dBu = 0.775 Vr.m.s.
Specifications
Outputs
Y/C OUT 4-pin mini DIN connector, 75 ohms
terminated
VIDEO OUT BNC connector, 75 ohms terminated
AUDIO OUT phono jack
R/R-Y OUT, G/Y OUT, B/B-Y OUT
BNC connector, 75 ohms terminated
EXT SYNC OUT BNC connector, 75 ohms terminated
DC OUT 5 V/1 A
Speaker output Output level 0.8 W
Remote input
REMOTE 1 8-pin mini DIN
See the pin assignment on the
page 14.
RS-232C 9-pin D-sub
See the pin assignment on the
page 14.
General
Classification of equipment
- Type of protection against electric shock
Class I equipment
- Degree of protection against electric shock
Type B equipment
- Degree of protection against harmful ingress of water
Ordinary equipment
- Degree of safety of application in the presence of a
flammable anaesthetic mixture
Not protected equipment
- Mode of operation Continuous operation
- Information concerning type and frequency of technical
maintenance Not need maintenance equipment
- Main power switch Functional switch
Power requirements 120 V AC, 50/60 Hz
1.3 A (PVM-1353MD)
1.6 A (PVM-1953MD)
Capable of 100 to 240V operation
Operating temperature range
0 – +35°C (32 – 95°F)
Storage temperature range
–10 – +40°C (14 – 104°F)
Humidity 0 – 90%
Pressure 860-1060 hpa
Dimensions PVM-1353MD
Approx. 346 · 340 · 411.5 mm
(w/h/d)
(13
5
/
8
· 13
1
/
2
· 16
1
/
4
inches)
PVM-1953MD
Approx. 450 · 457.5 · 503 mm
(w/h/d)
(17
3
/
4
· 18
1
/
8
· 19
7
/
8
inches)
not incl. projecting parts and controls
c
(continued)
