Specifications
Outputs
LINE A
Y/C OUT
4-pin
mini-DIN
(xl)
loop-through,
Automatic 75 ohms termination
VIDEO OUT
BNC connector
(xl)
loop-through,
Automatic 75 ohms termination
AUDIO OUT
Phono jack
(xl)
loop-through
Speaker output Output level: 0.8 W
General
CRT
PVM-14NlA/l4NlE/l4NlU/
14N2A/l4N2E/l4N2U:
14-inch CRT with P-22
phosphor
Visible picture size 340 mm
(13-inch
measured diagonally)
PVM-20NlA/20NlE/20NlU/
20N2A/20N2E/20N2U:
20-inch
CRT with P-22
phosphor
Visible picture size 490 mm 1
(
19-inch
measured diagonally)
Power consumption
PVM-14NlA/l4NlE/l4NlU:
80W
PVM-l4N2A/l4N2E/l4N2U:
80W
PVM-20NlU/20N2U:
1OOW
PVM-20Nl
A/20N2A/20NlE/
20N2E:
105 W
Power requirements
100 to 240 V AC,
50/60Hz
“For use o f
PVM-14N/
U/14N2U//
20N l
U/20N2
U”,
operate these
monitors on 120 V AC.
Operating temperature
0 to +35˚C (32 to
95˚F)
Storage temperature
-10 to
+40°C
(14
to 1O4˚F)
Relative humidity 0 to 90
%
Dimensions (w/h/d)
PVM-14N1A/l4N1E/l4NlU/
14N2A/l4N2E/l4N2U:
346X34Ox414 mm
(13
5
/8 x
13
1
/2
x
16
3
/8
inches)
PVM-20NlA/20NlE/20NlU/
20N2A/20N2E/20N2U:
449X44lx502mm
(17
3
/4
x l7
3
/
8
X
19
7
/8
inches)
Mass
Accesory
supplied
PVM-14NlA/l4NlE/l4NlU/
14N2A/l4N2E/l4N2U:
Approx. 15 kg (33 lb 1 oz)
PVM-20NlA/20NlE/20NlU/
20N2A/20N2E/20N2U:
Approx. 28 kg (61 lb 12 oz)
AC power cord (1)
Operating Instructions (1)
Pin assignment
Y/C IN connector (4-pin mini-DIN)
Pin No.
Signal
2
3
4
Y-input
CHROMA
subcarrier-input
GND for Y-input
GND for
CHROMA-input
Description
1 Vp-p, sync negative,
75 ohms
0.286 Vp-p (NTSC),
300m Vp-p (PAL),
burst
Delay time between Y
and C: within 0
±
100
nsec., 75 ohms
GND
GND
Design and specifications are subject to change
without notice.
14
