Location and Function of Parts and Controls
Rear Panel
LINE A connectors
LINE B connectors
RGB
connectors
-AClN
4REMOTE
connector
@-AC
IN connector
(The
w
mark indicates automatic termination.)
PVM-2ON2A/2ON2E/2ON2U
rear panel
@
LINE A connectors
When the cable is connected to this connector, the
75-
Input connectors for the composite video, Y/C separate
ohm termination of the input is automatically released,
video and audio signals and their loop-through output
and the signal input to the Y/C IN connector is output
connectors.
from this connector.
To monitor the input signal fed through these
connectors, press the LINE A button on the front
panel.
VIDEO IN connector
(BNC-type)
Connect to the video output connector of video
equipment, such as a VCR or a color video camera.
For a loop-through connection, connect to the video
output connector of another monitor.
The Y/C IN connector has priority over the VIDEO IN
connector.
When connecting the cable to the Y/C IN connector,
the Y/C IN connector is automatically selected and the
VIDEO IN connector is disconnected even if the cable
is connected.
Y/C IN connector
(4-pin
mini-DIN)
Connect to the Y/C separate output connector of a
video camera, VCR or other video equipment.
Y/C OUT connector
(4-pin
mini-DIN)
Loop-through output of the Y/C IN connector.
Connect to the Y/C separate input connector of a VCR
or another monitor.
VIDEO OUT connector
(BNC-type)
Loop-through output connector of the VIDEO IN
connector. Connect to the video input connector for a
VCR or another monitor.
When the cable is connected to this connector, the
75
ohm termination of the input is automatically released,
and the signal input to the VIDEO IN connector is
output from this connector.
AUDIO IN connector (phono jack)
Connect to the audio output connector of a VCR or
other equipment. For a loop-through connection,
connect to the audio output of another monitor.
6
To Next Page
