1. Overview: Features
7
MPC-3626
Imager mode Shooting frame rate De-Squeeze
Off(1.0×) 1.25× 1.3× 1.5× 1.65× 1.8× 2.0×
6K 3:2 1 to 60 Yes Yes Yes Yes Yes Yes Yes
6K 1.85:1 1 to 60, 66, 72 Yes – – – – – –
6K 17:9 1 to 60, 66, 72 Yes Yes Yes – Yes Yes Yes
6K 2.39:1 1 to 60, 66, 72, 75, 88, 90 Yes – – – – – –
5.7K 16:9 1 to 60, 66, 72 Yes – – – – – –
4K 6:5 1 to 60, 66, 72 Yes – – – – – Yes
4K 4:3 Surround 1 to 30 Yes – Yes – Yes Yes Yes
4K 4:3 1 to 60, 66, 72, 75 Yes – Yes – Yes Yes Yes
4K 17:9 Surround 1 to 48 Yes Yes Yes – Yes Yes Yes
4K 17:9 1 to 60, 66, 72, 75, 88, 90, 96,
100, 110
Yes Yes Yes – Yes Yes Yes
4K 2.39:1 1 to 60, 66, 72, 75, 88, 90, 96,
100, 110, 120
Yes – – – – – –
3.8K 16:9 Surround 1 to 48 Yes – – – – – –
3.8K 16:9 1 to 60, 66, 72, 75, 88, 90, 96,
100, 110
Yes – – – – – –
Surround View (MPC-3626)
Surround View is a mode available in the following imager modes that displays an image range
that includes a 5% outer region beyond the effective picture size (top/bottom/left/right) in the
viewfinder and SDI monitor output, allowing you to view a larger image range when shooting.
The recorded image area does not include the outer region.
4K 4:3
4K 17:9
3.8K 16:9
[Notes]
• In this mode, limitations on the maximum project frame rate setting may apply.
• In 4K 4:3 mode with de-squeeze ratio of 2.0×, the image area includes only 5% of the top and bottom outer
regions.
