3. Camera Operations
Project Menu
The functions and available settings of each menu item are given below.
Default values are shown underlined and in bold text.
Project > Basic Setting
Makes settings related to picture size and project frame rate.
Menu item Setting Description
Imager Mode
MPC-3628
8.6K 3:2/8.2K 17:9/
7.6K 16:9/5.8K 6:5/
5.8K 17:9/5.4K 16:9
MPC-3626
6K 3:2/6K 1.85:1/6K
17:9/6K 2.39:1/5.7K
16:9/4K 6:5/4K 4:3/4K 4:3
Surround View/4K 17:9/4K
17:9 Surround View/4K
2.39:1/3.8K 16:9/3.8K 16:9
Surround View
Selects the effective picture size.
[Notes]
• 5.8K 6:5 is displayed only when an Anamorphic
License is installed.
• 7.6K 16:9/8.2K 17:9/8.6K 3:2 are displayed only
when a Full-Frame License is installed.
• 6K 3:2/6K 1.85:1/6K 17:9/6K 2.39:1/5.7K 16:9
are displayed only when a Full-Frame License is
installed.
• 4K 6:5/4K 4:3/4K 4:3 Surround View are displayed
only when an Anamorphic License is installed.
Project Frame Rate 23.98/24/25/29.97/47.95/
50/59.94
Selects the project frame rate.
Input Color Space
When RM/RCP Paint Control
(page 91) is set to Off:
S-Gamut3.Cine/SLog3 /
S-Gamut3/SLog3 /
ACEScct
When RM/RCP Paint Control is
set to On:
S-Gamut3.Cine/SLog3 /
S-Gamut3/SLog3 /
ACEScct / HLG(Natural) /
HLG(Live) / Rec.2020/User
Gamma / Rec.709/User
Gamma
Sets the color space.
[Note]
HLG(Natural) is equivalent to HLG BT.2100.
Recording Format X-OCN XT/X-OCN ST/X-OCN
LT/ProRes 4444 4K/ProRes
4444 QFHD/ProRes 422 HQ
4K/ProRes 422 HQ QFHD
Selects the video format to be recorded on an
AXS memory card.
Base ISO
MPC-3628
ISO 800/ISO 3200
MPC-3626
ISO 500/ISO 2500
Sets the base sensitivity.
Project > Basic Setting
Makes settings related to picture size and project frame rate.
Menu item Setting Description
Anamo. De-Squeeze Off(1.0×)/1.25×/1.3×/1.5×/
1.65×/1.8×/2.0×
Sets the de-squeeze processing for ProRes
recording signals and video output signals.
This setting is available when an Anamorphic
License is installed and Imager Mode is set to
4K 4:3/4K 4:3 Surround View/4K 6:5/4K
17:9/4K 17:9 Surround View/5.8K 6:5/5.8K
17:9, or when an Anamorphic License and Full-
Frame License are installed and Imager Mode
is set to 6K 3:2/6K 17:9/8.2K 17:9/8.6K 3:2. The
options vary depending on the picture size.
MPC-3628
Imager Mode Anamo. De-Squeeze
Off(1.0×) 1.25× 1.3× 1.5× 1.65× 1.8× 2.0×
8.6K 3:2 Yes Yes Yes Yes Yes Yes Yes
8.2K 17:9 Yes Yes Yes – Yes Yes Yes
7.6K 16:9 Yes – – – – – –
5.8K 6:5 Yes – – – – – Yes
5.8K 17:9 Yes Yes Yes – Yes Yes Yes
5.4K 16:9 Yes – – – – – –
MPC-3626
Imager Mode Anamo. De-Squeeze
Off(1.0×) 1.25× 1.3× 1.5× 1.65× 1.8× 2.0×
6K 3:2 Yes Yes Yes Yes Yes Yes Yes
6K 1.85:1 Yes – – – – – –
6K 17:9 Yes Yes Yes – Yes Yes Yes
6K 2.39:1 Yes – – – – – –
5.7K 16:9 Yes – – – – – –
4K 6:5 Yes – – – – – Yes
4K 4:3 Surround Yes – Yes – Yes Yes Yes
4K 4:3 Yes – Yes – Yes Yes Yes
4K 17:9 Surround Yes Yes Yes – Yes Yes Yes
4K 17:9 Yes Yes Yes – Yes Yes Yes
4K 2.39:1 Yes – – – – – –
3.8K 16:9 Surround Yes – – – – – –
3.8K 16:9 Yes – – – – – –
