3. Camera Operations: Project Menu
73
Project > Basic Setting
Makes settings related to picture size and project frame rate.
Menu item Setting Description
Zoom to Fit
Off/17:9/16:9 You can set whether to cut out and magnify
the display of the recording image for the
viewfinder screen or Monitor output.
[Notes]
• Configurable under the following conditions.
Imager Mode: 8K 3:2/6K 3:2
Recording Format: X-OCN
Anamo. De-Squeeze: Off(1.0×)
• 16:9 cannot be selected when Project Frame Rate
is set to 47.95.
• If the setting is changed from 17:9 or 16:9 to
Off, the SDI output format returns to the default
setting.
Project > Assignable Button
Assigns functions to assignable buttons.
For details about assigning functions, see “User Functions Screen” (page 48).
Menu item Setting Description
<1> page 48 Assigns a function to assignable button 1.
<2> page 48 Assigns a function to assignable button 2.
<3> page 48 Assigns a function to assignable button 3.
<4> page 48 Assigns a function to assignable button 4.
<VF A> page 48 Assigns a function to assignable button A on
the viewfinder (DVF-EL200).
<VF B> page 48 Assigns a function to assignable button B on
the viewfinder (DVF-EL200).
<VF C> page 48 Assigns a function to assignable button C on
the viewfinder (DVF-EL200).
<User 1> page 48 Assigns a function to ITEM key 1.
<User 2> page 48 Assigns a function to ITEM key 2.
<User 3> page 48 Assigns a function to ITEM key 3.
<User 4> page 48 Assigns a function to ITEM key 4.
<User 5> page 48 Assigns a function to ITEM key 5.
Project > Special Recording
Makes settings related to picture cache recording.
Menu item Setting Description
Cache Rec Select
On/Off Turns the picture cache recording function
on/off.
Project > Special Recording
Makes settings related to picture cache recording.
Menu item Setting Description
Max Cache Rec
Duration
2 s/4 s/6 s/8 s/10 s/15 s/
24 s/30 s
Sets the playback duration of video to cache
in picture cache memory.
The maximum value that can be set for an
AXS memory card is given below.
[Note]
When FPS is set to Variable, the actual playback
duration will vary from the Max Cache Rec Duration
setting.
X-OCN recording
MPC-3628
Imager
Mode
Recording
Format
Project Frame Rate
23.98 24 25 29.97 47.95 50 59.94
8.6K 3:2 X-OCN XT 4 4 4 2 – – –
X-OCN ST 10 10 8 6 – – –
X-OCN LT 15 15 15 15 – – –
8.2K 17:9 X-OCN XT 8 8 8 6 – – –
X-OCN ST 15 15 15 10 4 4 2
X-OCN LT 30 30 30 24 10 10 8
7.6K 16:9 X-OCN XT 8 8 8 6 – – –
X-OCN ST 15 15 15 10 – 4 2
X-OCN LT 30 30 30 24 – 10 8
5.8K 6:5 X-OCN XT 10 10 10 8 2 – –
X-OCN ST 15 15 15 15 8 – –
X-OCN LT 30 30 30 30 15 – –
5.8K 17:9 X-OCN XT 24 24 24 15 8 8 6
X-OCN ST 30 30 30 30 15 15 10
X-OCN LT 30 30 30 30
30 30 24
5.4K 16:9 X-OCN XT 24 24 24 15 – 8 6
X-OCN ST 30 30 30 30 – 15 10
X-OCN LT 30 30 30 30 – 30 24
