Using Your VAIO Computer
To connect in CATV mode (Option 2)
1 Connect the two metal hooks on a 75-ohm/300-ohm RCA transformer cable (1) (not supplied) to the screw-type grips at
your cable service access (wall outlet) (2).
2 Connect one end of a TV coaxial cable (3) to the transformer end of the RCA transformer cable (1). Connect the other
end to the VHF/UHF input port (4) on the computer.
