Connecting the Projector
Preparation
OUTPUT
Projected images and input audio can be output to display equipment such as a monitor and
audio equipment such as speakers with a built-in amplifier.
Projected images and audio can be output. The image is output only as a computer signal input from
the RGB input connector (INPUT A/INPUT B (INPUT B is available only for VPL-EX120/EX145/
EX175)) or a video signal input from the YP
BPR input connector (INPUT A).
Connecting an External Monitor and Audio Equipment
Note
Mini D-sub 15-pin
cable (supplied)
RGB input
connector
Display equipment
Audio input
connector
Audio cable
(stereo mini plug)
(not supplied)
Audio equipment
