Service Manual
-16 -
Audio Output (Digital) Optical output :- (Digital PCM output) (Complies
with IEC958 Consumer Mode )
1 x (3.5mm Jack type) – as part of 3.5mm
Combination Connector.
RF Outputs 1 x RF Male Connector, (looped through
DTT Tuner )
Maximum RF loss = < 9dBm
• Signal Processing
Descrambler DVB Common Scrambling
Demultiplexer MPEG2, ISO / IEC 13818-1
Video Decoder MPEG2 MP@ML up to 15Mbps / ETR154
Audio Decoder MPEG1 Layer 1&2 (32, 44.1, 48 KHz Sampling)
ETR154
• CPU/Memory Configuration (expandable as option)
Multimedia CPU DTV Processor / Decoder, NEC EMMA2(Light)
Family (UPD 61120F1-100-JN1) non Macro Vision
MM CPU Main Memory 1x 128Mbit DDR SDRAM (option for 256Mbit)
1 x 64Mbit NAND Flash (option for 128 Mbit)
• Graphics Capability
Bitmap ARGB 8888
Resolution 720 x 576
• Software
Operating System Nucleus +
