IC601 - PQ025EZ01ZP
This is a fixed 2.5V regulator, its main function is to supply the PWB with a 2.5V supply.
IC701- LM317LMX
This is a variable voltage regulator, its main function is to supply IC700 with a 5V supply.
List of Specification Sheets included on Service Manual CD
TU1000 - BTD-DU606Z
IC600 -TOP244Y
IC800 - CXA7002R-T6
IC700 - XWM8729ED/R
IC200 - FS6128-04
IC201 - UPD61120F1-100-JN1
IC300 / IC304 - TC58V64BFTEL, Y
IC302 - MT46V8M16TG-75
IC604 - PQ015EZ01ZP
IC601 - PQ025EZ01ZP
IC701- LM317LMX
