– 7 –
MAIN BOARD
BELT (F4)
2
screw (M1.4) (toothed lock)
3
MAIN board
2
screw
2
screw
1
Remove six solders of
head flexible board.
1
Remove seven solders of “motor, DC (M601)”.
1
Remove two solders of
“solenoid, plunger”.
1
Remove four solders of
“switch, leaf (S704)”
slider
S702
Note:On installation
MAIN board adjust
the S702 and slider.
2
terminal board, battery
1
Remove solder of
“terminal board, battery”.
3
belt (F4)
pulley, motor
pulley, reverse
flywheel (R),
insert
belt (F4)
flywheel (N), insert
w
w
w
.
