Sony Walkman WM-EX910 Service Manual

– 8 –
MOTOR, DC (CAPSTAN/REEL) (M601)
LID SUB ASSY, CASSETTE
2 motor, DC (capstan/reel) (M601
)
1 two screws (M1.4)
2 two screws (MI)
2 scre
w
3 boss
1 Open “lid assy, cassette”.
4 lid sub assy, cassette
