Sony WALKMAN WM-FS420RS - WATER PROOF SECTION

— 3 —
SECTION 2
SERVICE NOTE
WATER PROOF SECTION
Note : In case the parts in the figure are removed for repair, treat them to protect from water drop following the instructions in the figure
(spread grease, bond etc.)
• Sony grease SGL-601 : 7-651-000-10
Tapping screw (B)(1.4 × 4)
Tapping screw (B)(1.4
× 4)
Joint (AVLS)
Joint (VOL)
Knob (Hold)
Knob (Vol)
Ring. O
(Apply sony grease: SGL-601
)
Ring (Dia. 2.5 × Dia. 4.5). O
(Apply sony grease: SGL-601)
