5
WM-FX495
SECTION 3
DISASSEMBL
Y
Note :
Follow the disassembly procedure in the numerical order given.
3-1.
CABINET (FRONT) SUB ASSY
z
The equipment can be removed using the following procedure.
MAIN board
Cassette holder sub ASSY
Mechanism deck
Set
Cabinet (front) sub ASSY
8
Cabinet (front) sub ASS
Y
6
Claws
5
Claws
7
1
2
Screw (B 1.7
×
9), tapping
4
Claws
3
Screw (B 1.7
×
9), tapping
Cabinet center
4
6
Table of Contents
Specifications
1
Table of Contents
2
1 Servicing Note
3
2 General
4
3 Disassembly
5
Cabinet (Front)Sub Assy
5
Main Board
6
Mechanism Deck
6
Cassette Holder Sub Assy
7
4 Adjustments
8
Mechanical Adjustments
8
Electrical Adjustments
8
5 Diagrams
11
Block Diagram
11
Printed Wiring Boards
12
Schematic Diagram -Main Section (1/2)
13
Schematic Diagram -Main Section (2/2)
14
IC Block Diagrams
15
6 Exploded Views
17
Cabinet Section
17
Mechanism Deck Section
18
(Mf-Wmfx495-147)
18
7 Electrical Parts List
19
