6
WM-FX495
3-3. MECHANISM DECK
3
Mechanism deck
Cabinet (center) ASS
Y
1
Claws
2
3-2. MAIN BOARD
Cabinet (center) ASSY
1
Unsolder HEAD flexible board
5
Claws
4
Screw (1.7
×
2.5), tapping
2
Unsolder leads from motor (four places)
3
Unsolder L4 leads (three places)
7
MAIN board
6
