Cabinet center
• Use caution when installing the cassette holder assy
Install the cassette holder sub ASSY with the spring (lid up)
as shown below in the drawing so that it fits into the holes
on the cabinet center. Once installed, fit the left and right
pieces on.
• Press on the left & right clips from the rear of the
cabinet center and remove the boss.
2
1
To Next Page
