Sony WM-GX512 - SECTION 8. ELECTRICAL PARTS LIST

— 31 —
NOTE: • Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
• CAPACITORS
uF : µ F
• COILS
uH : µ H
REF. No. Part No. Description Remark
REF. No. Part No. Description Remark
C305 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C306 1-109-996-11 CERAMIC CHIP 1uF 6.3V
C307 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C308 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C309 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C310 1-109-996-11 CERAMIC CHIP 1uF 6.3V
C311 1-135-221-11 TANTAL. CHIP 3.3uF 20% 4V
C312 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C313 1-109-996-11 CERAMIC CHIP 1uF 6.3V
C316 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C321 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C501 1-135-250-11 TANTAL. CHIP 4.7uF 20% 4V
C502 1-135-316-11 TANTAL. CHIP 22uF 20% 2.5V
C505 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C507 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C508 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C509 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C510 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C513 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C514 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C515 1-109-996-11 CERAMIC CHIP 1uF 6.3V
C516 1-109-996-11 CERAMIC CHIP 1uF 6.3V
C517 1-163-011-11 CERAMIC CHIP 0.0015uF 10% 50V
C518 1-163-011-11 CERAMIC CHIP 0.0015uF 10% 50V
C519 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C520 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C521 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C522 1-164-172-11 CERAMIC CHIP 0.0056uF 10% 25V
C524 1-164-695-11 CERAMIC CHIP 0.0022uF 5% 50V
C525 1-162-958-11 CERAMIC CHIP 270PF 5% 50V
C526 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C527 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C601 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C602 1-109-996-11 CERAMIC CHIP 1uF 6.3V
C603 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C604 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C605 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C606 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C607 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C608 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
SECTION 8
ELECTRICAL PARTS LIST
1-658-564-11 ATS FLEXIBLE, BOARD
*******************
< SWITCH >
S903 1-762-080-11 SWITCH,LEAF (ATS SWITCH)
**************************************************************
A-3016-778-A MAIN BOARD, COMPLETE (GX510)
****************************
A-3016-752-A MAIN BOARD, COMPLETE (GX512)
****************************
* 1-537-981-11 CONDUCTIVE BOARD, CONNECTION
< CAPACITOR >
C101 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C102 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C103 1-135-316-11 TANTAL. CHIP 22uF 20% 2.5V
C104 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C105 1-109-996-11 CERAMIC CHIP 1uF 6.3V
C106 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C107 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C108 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C109 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C110 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C111 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C201 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C202 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C203 1-135-316-11 TANTAL. CHIP 22uF 20% 2.5V
C204 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C205 1-109-996-11 CERAMIC CHIP 1uF 6.3V
C206 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C207 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C208 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C209 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C210 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C211 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C301 1-107-520-11 TANTAL. CHIP 33uF 20% 2.5V
C302 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C303 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
MAINATS FLEXIBLE
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board
name.
