71
XAV-701BT/741
SECTION 7
ELECTRICAL PARTS LIST
A-1871-829-A DISPLAY BOARD, COMPLETE
(XAV-701BT: E (PAL), SAF, RU)
A-1871-830-A DISPLAY BOARD, COMPLETE (XAV-741)
A-1905-945-A DISPLAY BOARD, COMPLETE
(XAV-701BT: E (NTSC))
********************
When DISPLAY board is defective, exchange the complete mounted board.
************************************************************
A-1871-832-A D-SUB7 BOARD, COMPLETE
**********************
< CONNECTOR >
CN7301 (Not supplied) CONNECTOR, FFC/FPC (ZIF) 60P
CN7302 1-843-289-11 CONNECTOR, BOARD TO BOARD 60P
< RESISTOR >
R7311 1-218-990-81 SHORT CHIP 0
R7312 1-218-990-81 SHORT CHIP 0
R7313 1-218-990-81 SHORT CHIP 0
R7314 1-216-864-11 SHORT CHIP 0
************************************************************
A-1871-816-A EXT-NAVI BOARD
(Included in CONNECTOR ASSY (NV1))
**************
< CAPACITOR >
C602 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C603 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C604 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C605 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C606 1-124-589-11 ELECT 47uF 20% 16V
C607 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C608 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C609 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C610 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN601 1-842-501-11 CONNECTOR (BUS) (EXT)
* CN603 1-566-767-11 PIN, CONNECTOR (PC BOARD) 12P
< IC >
IC601 6-718-920-01 IC BA3123F-E2
< TRANSISTOR >
Q601 6-552-430-01 TRANSISTOR DRC5114E0L
Q602 6-552-430-01 TRANSISTOR DRC5114E0L
Q603 6-552-430-01 TRANSISTOR DRC5114E0L
Q604 6-552-430-01 TRANSISTOR DRC5114E0L
< RESISTOR >
R600 1-216-864-11 SHORT CHIP 0
R602 1-216-864-11 SHORT CHIP 0
R603 1-216-864-11 SHORT CHIP 0
R607 1-216-864-11 SHORT CHIP 0
R608 1-216-864-11 SHORT CHIP 0
R609 1-216-864-11 SHORT CHIP 0
R610 1-216-864-11 SHORT CHIP 0
R611 1-216-864-11 SHORT CHIP 0
R612 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W
R619 1-218-937-11 METAL CHIP 47 5% 1/16W
R620 1-218-937-11 METAL CHIP 47 5% 1/16W
R621 1-218-935-11 METAL CHIP 33 5% 1/16W
R622 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R623 1-218-965-11 METAL CHIP 10K 5% 1/16W
R625 1-218-953-11 METAL CHIP 1K 5% 1/16W
R627 1-218-965-11 METAL CHIP 10K 5% 1/16W
R628 1-218-965-11 METAL CHIP 10K 5% 1/16W
R629 1-216-864-11 SHORT CHIP 0
R640 1-216-864-11 SHORT CHIP 0
R641 1-216-864-11 SHORT CHIP 0
R642 1-216-864-11 SHORT CHIP 0
R643 1-216-864-11 SHORT CHIP 0
R644 1-216-864-11 SHORT CHIP 0
R645 1-216-864-11 SHORT CHIP 0
R646 1-216-864-11 SHORT CHIP 0
R647 1-216-864-11 SHORT CHIP 0
R649 1-216-864-11 SHORT CHIP 0
************************************************************
A-1871-827-A KEY7 BOARD, COMPLETE
********************
4-434-130-02 SHEET (KEY7)
< FLEXIBLE FLAT CABLE >
FFC3 1-839-932-11 CABLE, FLEXIBLE FLAT (20 CORE)
When KEY7 board is defective, exchange the complete mounted board.
************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
RU : Russian model
SAF : South African model
Note 1: When complete DISPLAY board is exchanged,
exchanged old complete DISPLAY board and
is destroyed with the hammer, and throw out it.
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Note 2: CN7301 cannot exchange with single.
When this part is damaged, exchange
the complete mounted board.
DISPLAY D-SUB7
EXT-NAVI KEY7
Ver. 1.2
To Next Page
