– 10 –
FRONT PANEL ASS’Y
COVER ASS’Y
Note: Follow the disassembly procedure in the numerical order given.
SECTION 2
DISASSEMBLY
1
Push the button
(release).
2
Remove the front panel ass’y
to the direction of the arrow
A
.
A
1
1
1
2
2
2
3
cover ass’y
