2. Install the removed parts by reversing the steps of removal.
Tip
The protection sheet (NET-28) is attached to the NET-28/NET-28A board as following procedures.
(1) Bend the protection sheet (NET-28) to the line.
Protection sheet (NET-28)
Bend line
(2) Attach the protection sheet (NET-28) to the board.
(3) Cover the "a" portion of protection sheet (NET-28) to the connector (CND1).
XVS-9000-C/XVS-8000-C/XVS-7000-C/XVS-6000-C
4-16
