4-13. HN-442 Board
Preparation
1. Remove the front panel. (Refer to “4-2. Front Panel”)
2. Remove the front board. (Refer to “4-6. Front Board”)
Tip
Remove as many front boards as required for easily replacing the HN-442 board.
Procedure
1. Remove the two screws, then remove the HN-442 board assembly.
PSW3 x 6
HN-442 board assembly
XVS-9000-C/XVS-8000-C/XVS-7000-C/XVS-6000-C
4-26
To Next Page
