CAMERA BUTTONS
1. Zoom lever
2. ASSIGN 4 - focus magnifier
3. Microphone holder
4. ASSIGN 5 - Iris Push Auto
5. ASSIGN 6 - Zebra
6. Recording lamp - flashes when capacity of
memory card or battery becomes low.
7. NightShot light
8. Tripod mounting screw
9. Battery release
1. SDI OUT Jack
2. Start/Stop record button
3. HDMI OUT jack
4. DC IN jack
5. U/D/L/R - SET toggle buttons
6. Handle zoom lever
7. Handle record button
8. INPUT 2 jack
9. INPUT 1 jack
10. Remote jack
1. Slot Select for SD cards
2. Thumbnail Playback button
3. LCD Screen
4. Power Button
5. White Balance
6. ASSIGN 1 - S&Q button
7. ASSIGN 2 - Status Check
8. ASSIGN 3 - Picture Profile
9. Display Button
10. Memory card slot A
11. Memory card slot B
