ZS-H10CP/H20CP
6
• This set can be disassembled in the order shown below.
3-1. DISASSEMBLY FLOW
Note 1: The process described in can be performed in any order.
Note 2: Without completing the process described in , the next process can not be performed.
Note 3: Illustration of disassembly is omitted.
SECTION 3
DISASSEMBLY
3-5. OPTICAL PICK-UP
(KSM-213CDP)
(Page 8)
3-8. KEY (POWER) BOARD/
JACK BOARD
(Page 10)
3-7. MAIN BOARD
(Page 9)
3-9. JOG BOARD
(Page 10)
3-6. POWER BOARD
(Page 9)
3-11. TU BOARD
(Page 11)
3-12. DC JACK BOARD
(Page 12)
3-4. CD BLOCK ASSY
(Page 8)
3-3. CABINET (REAR)
ASSY
(Page 7)
3-10. KEY (PLAY) BOARD
(Page 11)
3-2. BASE (HANDLE L)/(HANDLE R),
HANDLE ASSY
(Page 7)
