Technical specifications
Sophos AP 30
Chassis Plastic housing, white (smoke detector design)
Maximum throughput 300 Mbit/s
LAN interfaces 1 x 10/100 Base-TX
Supported WLAN standards 802.11 b/g/n 2.4 GHz
Antennas 2 x directional internal antennas (4 dBi)
Frequencies / channels 2.412~2.462 GHz Channels 1-11
Power supply 100-240 VAC, 50/60 Hz, max. 0.5 A
Power consumption 8 W (max.)
Power-over-Ethernet Yes (IEEE 802.3af) – 48 VAC/0.375A
Dimensions ø 120 mm, height 50 mm
Weight 230 g
Temperature range Operating: 0°C to 45°C Storage: -20°C to 70°C
Humidity (non-condensing) 5% to 95%
Mounting Desktop / ceiling
Supported security standards WPA/WPA2, WEP, 802.1X (RADIUS)
Number of supported SSIDs 8
Regulatory compliance CE FCC MIC/VCCI (Japan)
Radio: EN 300328 CFR 47, Part 15
Subpart C
Certification ID:
201 WW 11215238
EMC: EN 301489-1, EN
301489-17
CFR 47, Part 15
Subpart B
V-3/2011.04
V-4/2010.04
EMF: EN 50385 FCC 1.1310, IEEE C95.1 N/a
Safety: EN 60950-1 N/a N/a
