Technical specifications
Sophos AP 100
Chassis Plastic housing, white
Physical security Kensington lock
Maximum theoretical throughput 1.3 Gbps (5GHz / 802.11ac) + 450 Mbps (2.4GHz / 802.11n)
LAN interfaces 1 x 10/100/1000 Base-TX
Supported WLAN standards 802.11a/b/g/n/ac
Antenna 3 x detachable dipole antenna (2 dBi) Connector type: RP-SMA
Frequencies / channels ETSI
2.412–2.472 GHz (Channels 1-13) RLAN sub-band 1:
5.180-5.320GHz (channels 36-64)
RLAN sub-band 2:
5.500-5.580GHz (channels 100-116)
5.660-5.700GHz (channels 132-140)
FCC
2.412-2.462GHz (channels 1-11) U-NII-1:
5.180-5.240GHz (channels 36-48)
U-NII-2:
5.260-5.320GHz (channels 52-64)
U-NII-2e:
5.500-5.580GHz (channels 100-116)
5.660-5.700GHz (channels 132-140)
U-NII-3:
5.745-5.825GHz (channels 149-165)
Power supply 12 Vdc / 4 A
Power consumption 13 W (max.)
Power-over-Ethernet 802.3af, 802.3at
Dimensions W x H x D 183 x 36 x 183 mm
Weight 505 g
Temperature range Operating: 0°C to 50°C
Humidity (non-condensing) 0% to 90%
Mounting Desktop / wall
Supported security standards WPA/WPA2, WEP, 802.1X (RADIUS)
Number of supported SSIDs 8 per radio (16 in total)
Regulatory compliance CE FCC
Radio: EN 300 328, EN 301 893 CFR 47, Part 15 Subpart C, E
EMC: EN 301 489-1, EN 301 489-17 CFR 47, Part 15 Subpart B
EMF: EN 50385 FCC 1.1310, IEEE C95.1
Safety: EN 60950-1 N/a
