Technical specifications
APX 320X
Environment
Power consumption 18.9 W (max.)
Power over Ethernet
(PoE) requirements
802.3at
Operating temperature -40° to 55° C
Storage temperature -40° to 80° C
Humidity 10-95% non-condensing
Hazardous substances RoHS-2 and REACH compliant
Physical specification
I/O ports 1x RJ45 10/100/1000 Ethernet w/PoE (802.3at)
1x Reset button
Memory 512 MByte DDR3L
512 Mbyte NAND Flash
16 Mbyte SPI NOR Flash
Mounting Wall-mount hang
Pole mount
Dimensions
(Width x Depth x Height)
260.5 x 180 x 87 mm (10.26 x 7.09 x 3.43 inches)
Weight 1.42 kg (3.13 lbs)
Wireless specification
Radios 1x 2.4 GHz/5 GHz dual-band
1x 5 GHz single band
1x Bluetooth low energy (BLE for future use)
Antennas 4x omni-directional external dual-band
antennas for Radio-0 and Radio-1
1x internal 2.4 GHz antenna for BLE
Antenna Peak Gain 3.2 dBi at 2.4 GHz, 6.0 dBi at 5 GHz
MIMO capabilities 2x2:2
Supported WLAN standards IEEE 802.11 a/b/g/n/ac Wave 2 (Wi-Fi 5)
SSIDs 8 per radio, 16 in total (with dual radios active)
Max. Throughput Dual 5 GHz Mode
*
: up to 867 Mbps (5 GHz) + 867 Mbps (5 GHz)
Dual-band Mode
*
: up to 300 Mbps (2.4 GHz) + 867 Mbps (5 GHz)
Single 5 GHz Mode
**
: up to 867 Mbps
* Not available in the countries listed here: https://support.sophos.com/support/s/article/KB-000039850
** For the countries listed here: https://support.sophos.com/support/s/article/KB-000039850
Performance
Band/Mode Data Rate TX Power
Maximum
EIRP (dBm)
RX Sensitivity
(dBm)
2.412-2.472 GHz
(11b)
1 Mbps 24 -93
2 Mbps 24 -90
5.5 Mbps 24 -86
11 Mbps 24 -82
2.412-2.472 GHz
(11g)
6 Mbps 24 -89
9 Mbps 24 -88
12 Mbps 23 -86
18 Mbps 23 -84
24 Mbps 22 -81
36 Mbps 22 -77
48 Mbps 21 -73
54 Mbps 21 -72
