CENTRIFUGES RT/T6000D and RT/T6000B centrifuges
Serial Numbers 9101800 and Above
Table 9-13 Parts: Lid Latch Mechanism
(keyed to figure 9-26)
ITEM P/N DESCRIPTION QTY.
1
07821 Latch Assembly, kit (Sold in kit)
1
2 67350 Retaining Ring, External, Carbon Steel, 0.219 shaft diameter 2
3
07543
Linkage, Latch
1
4
64591
Lubricant, Plastilube® 1
5
07821 Latch Assembly, kit (Sold in kit)
1
6
63016
Lockwasher, Split, SST, No. 10 x 0.040" Thick *
7
61597
Screw, Machine, Pan Head, Slotted, SST, UNF, No. 10-32 x
3/8" Long
**
8
61817
Screw, Machine, Pan Head, Slotted, SST, UNC, No. 10-24 x
1/4" Long
4
9
07567
83166
Shaft Assembly (Short style shaft, 3.10 inches), Latch
Shaft Assembly (Long style shaft, 3.75 inches), Latch
1
10
07518
Bracket Assembly, Solenoid 1
11
66753
Microswitch, SPDT, Leaf Type 1
12 62587 Insulator, Switch, 1-15/32 x 1" Wide; 1
13 62396 Screw, Machine, Pan Head, Slotted, SST, UNC. No. 4-40 x
5/8" Long
2
14 61072 Flatwasher, SST, No. 4, 0.125 I.D. x 0.025 O.D. x 0.022"
Thick
2
15
63004
Lockwasher, Split, SST, No. 4 x 0.020" Thick 2
16
07578
Linkage Assembly, Manual Release 1
17
07629
Solenoid Assembly 1
18 07652 Pin, Actuator 1
19
67866
Switch, Push Button, DPDT, 15A, 125/250 Vac 1
20 60224 Screw, Fillister Head, Slotted, SST, UNC., No. 6-32 x 1" Long 2
21
60522
Flatwasher, SST, No. 4, 5/32 I.D. x 3/8 O.D. x 0.031" Thick 2
22 62021 Lockwasher, Split, No. 6 x 0.031" Thick 2
23
07606
Insulator, Fish Paper, 2.9 Long x 1.0 Wide x .031" Thick
* Three each required for lid latch without interlock; seven each required for lid latch with interlock.
** Three each required for lid latch without interlock; four each required for lid latch with interlock.
