SoundCraft Vi Series Technical Information

64 Analogue
Mic/Line Inputs
(48 on Soundcraft Vi4)
Optional 4 pairs of
AES/EBU inputs card
RS2446
(replaces 8 Mic/Line
inputs)
35 Analogue
Line Outputs
(27 on Soundcraft Vi4)
Optional 4 pairs
AES/EBU outputs card
RS2447
(replaces 8 Line
outputs)
16 Analogue Line
Inputs
16 Analogue Line
Outputs
8 pairs of AES/EBU
inputs
8 pairs of AES/EBU
outputs
8 GPIO Contact
Closures
Cat5 Data Link
3 (LCR) local
monitor A Analogue
Line outputs
2 (LR) local
monitor B Analogue
Line outputs
Talkback Line Output
64 Channel MADI I/O
Redundant
64 Channel MADI I/O
connection
16 GPIO Contact
Closures
Stage Box
Local Rack
Console Surface
Phones & TB Audio
System Hardware Diagram

SoundCraft Vi Series Specifications

General

Category	Digital Mixer
Input Channels	Up to 64
Output Busses	Up to 32
EQ	4-band parametric per channel
Connectivity	MADI, AES/EBU
Remote Control	iPad app available
Digital I/O	MADI, AES/EBU
Display	Touchscreen
Series	Vi Series
