A) Recording mode
I) Phono recoding
1) Rotate the Function button to select “ Phono “ mode. Place the recorded vinyl & get ready for playback.
2) Press “ Rec “ button (12/43) and then press the CD “ Play/Pause ” button (13/36) until the play indicator “
“ show on LCD display.
3) After few seconds, the LCD (3) will show the time counter and now the system is start recording process. Now start the
playback of the vinyl at phono.
4) After completing of recording, press the “ Stop ” (11/38) button and then stop the playback of vinyl.
II) Cassette recording
1) Rotate the Function button to select “ Tape “ mode. Place the recorded cassette tape to the cassette slot to get ready for
playback.
2) Press “ Rec “ button (12/43) and then the CD “ Play/Pause ” button (13/36) until the play indicator “ “ show on
LCD display.
3) After few seconds, the LCD (3) will show the time counter and now the system is start recording process. Now push the
cassette tape to the cassette compartment to start playback of which the track you prepare to record.
4) After completing of recording, press the “ Stop ” button (11/38) and then stop the playback of the cassette tape.
III) Aux-in recording
1) Rotate the Function button to select “ Aux “ mode. Connect the headphone output at the audio device (such as mp3
player, CD player etc) to the 3.5mm aux-in jack via a 3.5 mm connecting cable (not provided).
2) Repeat the same procedures from step 2 as described on other recording model from above then start playback your
external device.
3) Adjust the volume output level at your audio player device if the recording level is too high.
IV) USB recording
1) Rotate the function button to select “ USB “. Plug-in the USB pen-drive with the face up & make sure it going into
completely and set USB in pause/stop mode.
2) Repeat the same procedures from step 2 as described on other recording model from above and start to playback the
USB .
4) Adjust the volume output level at your audio player device if the recording level is too high.
Remark:-
- The recording speed is 1:1 and according to the actual plying time of the playing source
- To suspend the recording process, press the “ Play/Pause ” button (13/36), “ busy “ briefly appear on LCD and the
recording is in pause. To re-start, press again the “ Play/Pause ” button (13/36) until the play indicator “ “ show
on LCD display (3).
B) Recording setting
I) Recording level
Record level can be adjust by REC LEVEL +/- button (40) at remote handset to avoid distortion once the record source level
was too high.
II) Track separation
You can divide the recording music track by track during recording by auto or manual mode:-
A) Auto mode
Press the “ Auto/Manual “ button (43) when prepare the recording function, the LCD will show -20db , -30db, -40db, the
“AUTO TRACK” icon will appear on LCD“
When the recording sound level has dropped below the -20 / -30 / -40 dB (record signal) respectively, the current track will
terminate and then generate a new track & continue the recording mode automatically.
Thus, you are recommended to set lower record level for the music source with clear performance such as USB and higher
record level for higher noise music source such as vinyl:-
“ – 20db or – 30db “ – for recording of USB or Aux-in with digital music source
“ – 30db or – 40db “ – for recording of Tape or Phono mode
“ ------- “ – auto mode off
Remark:-
The above is just a recommendation, the actual performance is various and depend on difference music source time by time.
thus, if the cut-off is always mis-judge for certain music file, please use manual mode instead.
B) Manual mode
Anytime when press the “ track separate “ “ button (43) once during recording at any mode, the system will generate a
new track and continuous the recording. the word “ busy “ will briefly show on LCD display (3), it mean the unit is creating a
new track successfully.
III) Finalize a CD-R(W) disc
You must convert the CD-R(W) disc into standard CD before playing at other audio CD player. This process is knows as
finalizing and a table of contents (TOC) will written to the CD on the same time:-
