Page 8
For Technical Support - Please Call 1-800-338-7337
or visit www.soundoffsignal.com
500 Series Control System and Siren Amplifier
ENGSA5(xxxSx)Rev. D - 07/2021
REPLACEMENT PARTS & ACCESSORIES
Part # Description
PSRN5CTRL1 500 Series Remote Control Panel - Push Button Siren Controls
PSRN5CTRL2 500 Series Remote Control Panel - Rotary Knob Siren Controls
PSRN5CTRL3 500 Series Console Control Panel - Push Button Siren Controls
PSRN5CTRL4 500 Series Console Control Panel - Rotary Knob Siren Controls
PSRN5LEG1 Replacement Button Legend Sheet for Console and Remote Panels
PSRNHHC2 Replacement Handheld Control Panel
PSRN5ANR1 Replacement Amplifier - 100w
PSRN5ANR2 Replacement Amplifier - 200w
PSRN5MC01 500 Series Microphone
PSRN5HDK1 Replacement Input, Output, & Power Harness Kit
PSRN5HDK3
Hardware Conversion Kit - Microphone to 500 Siren Direct Connect with
25 audio extension cable.
PSRN5HDK4
Hardware Conversion Kit - Microphone to 500 Siren Direct Connect
without extension cable.
PSRN5MMC1 Hardware Kit - Microphone Mounting Kit
PSRN5BLBK1 Hardware Kit - Bail Bracket
AFTERMARKET SYSTEM HARNESS OPTIONS*
Part # Description
911 Circuits
911.500.10
10 Foot Harness Kit - Includes all labeled circuits for
connectors CN2, CN4, CN5, CN6, CN7, CN9, and CN12, at
10 feet long, and CN8 at 25 feet long.
Order directly from 911 Circuits - (503) 393-3444
911.500.25
25 Foot Harness Kit - Includes all labeled circuits for
connectors CN2, CN4, CN5, CN6, CN7, CN8, CN9, and
CN12, at 25 feet long.
Order directly from 911 Circuits - (503) 393-3444
Patrol Power
SOSBP500-10
10 Foot Harness Kit - Includes all labeled circuits for
connectors CN2, CN4, CN5, CN6, CN7, CN9, and CN12, at
10 feet long, and CN8 at 25 feet long.
Order directly from Patrol Power - (833) 701-1930
SOSBP500-25
25 Foot Harness Kit - Includes all labeled circuits for
connectors CN2, CN4, CN5, CN6, CN7, CN8, CN9, and
CN12, at 25 feet long.
Order directly from Patrol Power - (833) 701-1930
HARNESS ASSEMBLY PART NUMBERS (BUILD YOUR OWN)
Part Description
Connector
CN1
Crimp Ferrule Connection (over bare wire)
Ferrule Crimp Tool: American Electrical SQ28-10 (or equivalent)
Installation/Extraction Tool: 1/8” Allex Hex Key
Connector
CN2
Connector Housing: Hirose DF22R-3S-7.92C(28)
Pins: Hirose DF22A-1012SCF (Tin Terminals - Jxxxxx and lower)
Pins: Hirose DF22A-1012SCFA (Gold Terminals - Jxxxxx and higher)
Pin Crimp Tool (Recommended): Hirose HT103/DF22A-1012
Pin Crimp Tool (Optional): Match MOBCT1424 (or equivalent)
Extraction Tool: Flat Blade Screwdriver - 1.4mm Wide
Application Specification: https://bit.ly/3a54fEy
Connectors
CN4, CN5, CN6
Connector Housing: Molex 3901-2080
Pins: Molex 45750-3111 (Fits 5A or 10A Outputs, 16 AWG)
Pin Crimp Tool: Molex 200218-2200
Extraction Tool: Molex 1103-0044
Application Specification: https://bit.ly/3cifegs
Connector
CN7
Connector Housing: Molex 3901-2100
Pins: 3900-0039 (Bag) (Low Current Connections, 18-24 AWG)
Optional Pins: 3900-0038 (Reel) (Low Current Connections, 18-24 AWG)
Pin Crimp Tool: Molex 63819-0901
Extraction Tool: Molex 1103-0044
Application Specification: https://bit.ly/3t5cIQC
Connector
CN8
Connector Housing: Molex 3901-2040
Pins: 3900-0039 (Bag) (Low Current Connections, 18-24 AWG)
Optional Pins: 3900-0038 (Reel) (Low Current Connections, 18-24 AWG)
Pin Crimp Tool: Molex 63819-0901
Extraction Tool: Molex 1103-0044
Application Specification: https://bit.ly/3t5cIQC
Connector
CN9
Connector Housing: Molex 3901-2060
Pins: 3900-0039 (Bag) (Low Current Connections, 18-24 AWG)
Optional Pins: 3900-0038 (Reel) (Low Current Connections, 18-24 AWG)
Pin Crimp Tool: Molex 63819-0901
Extraction Tool: Molex 1103-0044
Application Specification: https://bit.ly/3t5cIQC
Connector
CN12
Connector Housing: Molex 171692-0102
Pins: 76823-0322 (12 AWG)
Pin Crimp Tool: Molex 63825-7100
Extraction Tool: Molex 63824-0810
Application Specification: https://bit.ly/3t3W2cw
TECHNICAL SPECIFICATIONS
General Information
Amplifier Dimensions 2.63" H x 7" W x 7" D
Full Size Control Panel 3.6" H x 7.2" W x 2.1" D
Handheld Control Panel 5" H x 2.5" W x 1" D
Input Voltage 10-16Vdc (Negative Ground)
Boxed Weight 10 lbs.
Operating Temperature -40°C to +65°C
Diagnostic LEDs
Control Panel Diagnostic LEDs (3),
Siren Amplifier LEDs (2)
Refer to Reference Table
Siren
Input Current
11 Amps @ 13.4 VDC - 100W System
22 Amps @ 13.4 VDC - 200W System
Standby Current
Ignition ON - 500mA
Ignition OFF - <4mA
Output Power
1x100W RMS Max (11 Ohm Speaker)
2x100W RMS Max (11 Ohm Speaker)
Siren Frequency 675Hz - 1633Hz
Over Voltage Protection Yes
Low Voltage Shutdown Programmable
California Title 13 Compliance Programmable
Hands Free Operation Programmable
Speaker Protection Short & Open
Light Control
Solid State Outputs
6 @ 10A
9 @ 5A
Slide Switch Relays
3 @ 20A
Not to exceed 50A total
Dry Contact Relays 2 @ 10A
Horn Ring Relay 1 @ 5A
Diode Isolated Outputs 3
Inrush Capable Outputs 6
Arrow Control Programmable
Control Panel Slide Switch Positions Off, 1, 2, 3 - Programmable
Control Panel Auxiliary Buttons 1-8, Programmable
Control Panel Siren Buttons
Standby, Wail, Yelp, Tone, Radio Rebroadcast, Manual,
Air Horn - All Programmable
Maximum Switch Current
75A (Excludes Horn Ring)
(Includes Relays and Solid State Switches)
TECH SPECS & REPLACEMENT PARTS
† This list is not intended to be fully inclusive or complete.
