FLASH PATTERN TABLE
BREAKOUT BOX HOOKUP:
Make sure the 24-pin connector and the RJ-45
connector are snapped in securely.
Follow the label for the wire color to connect to a
12Vdc source, which turns on that given light or
lights.
Make sure your wire connections are secured and
isolated from any other wire.
1
2
3
4
Solid Arrow Plus, Slow
Solid Arrow, Slow
Individual Arrow, Fast
Chaser Arrow, Fast
Grow / Decay
Solid
Individual
2X Individual
Directional Bar Directional Function Patterns For
Left, Center Out, & Right Sequences
1
2
3
4
5
RoadRunner™
PowerPulse™
Q-Switch™
ETM™
Steady Burn
Alternating
Alternating
Variable
Simultaneous
Steady Burn
115
180
-
214
-
1.92
3.00
-
3.57
-
LED Takedown & Alley Flash Patterns
1
2
3
4
5
6
7
8
9
PowerPulse™ Alternating
PowerPulse™ Alternating
Quad Alternating
Warp Alternating
Hyper Scan
Super Scan
Power Flash
Thunder and Lightning
Center Out
Left/Right
Center Out
Adjacent
2X Individual Sweep
Pulsing + Sweep
Dual Rate Pulse/Alt
Dual Rate Alt/Pulse
Random
180
180
80
350
-
-
-
-
-
3.00
3.00
1.35
5.88
-
-
-
-
-
Directional Bar Warning Function Patterns
10
11
12
13
14
15
16
17
RoadRunner™
Warp
Warp
Inter-Cycle Flash
Inter-Cycle Flash
Inter-Cycle Flash
Inter-Cycle Flash
Inter-Cycle Flash
Alternating
Adjacent
Adjacent
Adjacent
Alternating
Alternating
Alternating
Alternating
115
350
350
-
-
-
-
-
1.92
5.88
5.88
-
-
-
-
-
Split Arrow Bars Also Have The Following Multi-color Patterns
LED Module Flash Patterns
#
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
Pattern Name
Quint
Warp
Inter-Cycle Flash
Quad Flash
RoadRunner™
RoadRunner™
Slow Runner
Slow Runner
Q-Switch
™
Single, Steady Burn
Quad, Steady Burn
Warp, Steady Burn
Nothing, Steady Burn
E-Pattern Single Flash
E-Pattern Double Flash
E-Pattern Single Flash
E-Pattern Double Flash
Warp 1,2,3
Warp 2,3,1
Warp 3,2,1
Steady Burn
Sequence
Alternating
Alternating
Alternating
Alternating
Alternating
Simultaneous
Alternating
Simultaneous
Variable
Steady Burn
Steady Burn
Steady Burn
Steady Burn
Alternating
Alternating
Simultaneous
Simultaneous
Variable
Variable
Variable
Steady Burn
fpm*
70
350
-
80
115
115
70
70
-
115
80
350
-
230
128
230
155
-
-
-
-
fps**
1.18
5.88
-
1.35
1.92
1.92
1.16
1.16
-
1.92
1.35
5.88
-
3.85
2.13
3.85
2.6
-
-
-
-
*fpm=Flashes per Minute
**fps=Flashes per Second
FLASH PATTERNS AND CONNECTOR
INSTRUCTIONS
LIGHTBAR CONTROLLER CONNECTOR INSTRUCTIONS
Light Output Groups
Orange
Brown
Red and Yellow
Green
Blue
Red and Yellow (2-wire)
Green (2-wire)
Blue (2-wire)
White
Small Connector
Input Group Control
Front Corners
Rear Corners
Front Inboard 1
Front Inboard 2
Front Inboard 3
Rear Inboard 1
Rear Inboard 2
Rear Inboard 3
Front Takedown Flash
Alley Flash
PURPOSE
8-WIRE CONTROL
NO ARROW
N/A
4 MOD ARROW
5 MOD ARROW
6 MOD ARROW
7 MOD ARROW
8 MOD ARROW
PASSENGER-SIDE EXIT
DRIVER-SIDE EXIT
SPLIT-COLOR ARROW MODULES
FULL ARROW MODULE
FOR TURN SIGNALS ON YELLOW OUTPUT
FOR TURN SIGNALS ON BLUE OUTPUT
EPL 9000 SWITCH SETTINGS
SW1
Off
Off
Off
Off
On
On
On
On
SW2
Off
Off
On
On
Off
Off
On
On
SW3
Off
On
Off
On
Off
On
Off
On
SW4
On
Off
SW5
On
Off
SW6
On
Off
Page 13
