Soundoff Signal pinnacle User Manual

Technical SPECIFICATIONS
Input Voltage 10-16Vdc
Current Draw (Amps)
Average Peak Power Consumption
(Watts)
Inboard Module (ea): 0.5Amps @ 12.8Vdc 1.0Amps @ 12.8Vdc 6.4
Corner Module (ea): 1.0Amps @ 12.8Vdc 2.0Amps @ 12.8Vdc 12.8
Takedown Module (ea): 0.5Amps @ 12.8Vdc 1.0Amps @ 12.8Vdc 6.4
Alley Light Module (ea): 0.33Amps @ 12.8Vdc 0.65Amps @ 12.8Vdc 4.2
Average = Flashing Peak = 100% Steady ON
Standby Current: .022Amps@12.8Vdc Power Consumption = 0.28 Watts*
Reverse Polarity: Fuse Protected
Load Dump: Protected
Wiring: Power Cable 15ft 10AWG Wires, (+) RED, (-) BLK
Data Cable 15ft RJ-45 Type
Number of LEDs:
Inboard Module (ea) 6 Gen3 LEDs
Corner Module (ea) 12 Gen3 LEDs
Takedown Module (ea) 6 Gen3 LEDs
Alley Light Module (ea) 1 Multi Chip Gen3 LED
Operating Temperature: -40°C to +65°C
Light output:
Blue LED 30 Lumens minimum per LED
Red LED 50 Lumens minimum per LED
White LED 100 Lumens minimum per LED
White Multichip LED 400 Lumens minimum per LED
Amber LED 45 Lumens minimum per LED
Green LED 40 Lumens minimum per LED
Life: 50K+ hours
Optical Distribution:
Inboard Module (ea) 20° Vert. x 90° Horiz. Angle
Corner Module (ea) 20° Vert. x 120° Horiz. Anle
Takedown Module (ea) 20° Beam Angle
Alley Light Module (ea) 20° Beam Angle
Moisture Protection: IP66 sealed construction
Outer Lens: Polycarbonate with UV Protection
Mounting Bolt: n3/16” Stainless / A2
Dimensions:
36” Lightbar 35.4“L x 10.0”W x 2.9“H (end), 2.2”H (interior)
42” Lightbar 41.7“L x 10.0”W x 2.9“H (end), 2.2”H (interior)
48” Lightbar 48.0“L x 10.0”W x 2.9“H (end), 2.2”H (interior)
54” Lightbar 54.3“L x 10.0”W x 2.9“H (end), 2.2”H (interior)
60” Lightbar 60.7“L x 10.0”W x 2.9“H (end), 2.2”H (interior)
72” Lightbar 73.5“L x 10.0”W x 2.9“H (end), 2.2”H (interior)
*Based on configuration see page 12.
Page 3
