7. SPECIFICATIONS
Speaker Type Portable 2-way active speaker with rechargeable battery
Frequency response 80Hz-20KHz
Max. SPL 110* dB
LF 6,5"
HF type 1” Compression Driver
Directivity (HxV) 90° x 60°, Symmetric
Crossover Frequency 5.1 kHz
Amp Power (Program/Peak) 150W* / 300W*, Class-D
Controls
2xMic/Line level, UHF Mic Level, AUX/Bluetooth/MP3 level, AUX-MP3
Switch, Master level
2-Band EQ (BASS/TREBLE) Bass 100Hz (+/- 12dB); Treble 10kHz (+/- 12dB)
Connections 2xMic/Line Combo, AUX Stereo Mini Jack, Line In L&R RCA Jack
Indicators Power, Clip, Wireless Mic On, RF Mic, Battery Charge
Media player USB, SD-Card, Bluetooth™, LCD Display
Media player controls Stop, Play/Pause, Next track, Previous track, Mode
Power
Mains: 19V - 3,42A
Rechargeable Battery: 12V-2600mAH Lead Battery
Battery Model Name: TP12-2.6
Battery Size (WxHxD): 70mm x 47mm x 100mm
Charge/Discharge Cycle: 2hours / 5hours
Wireless Microphone
Frequency: UHF 863-865MHz (863.1 MHz)
Frequency Response: 50Hz – 17kHz
Transmitter Power: 10mW
Receiving Sensitivity -90 dBm
Total Harmonic Distortion < 0,1%
Modulation Type: FM
Battery Voltage: 3V (2x1.5V AA-Type Batteries)
Continuous Using: 7 hours
Hand-held Mic. Size (W/DxH): Ø35 (min) - Ø52 (max) x 245 mm
Hand-held Mic. Net Weight: 0.245 kg (batteries included)
Mechanics
Housing / Grille material Polypropylene / 0-8mm Steel
Handles 1 on top
Padded Cover YES
Pole Mount Standard D36 mm
Speaker Dimension (WxHxD) 220 x 320 x 200 mm
Packing Dimension (WxHxD) 420 x 633 x 340 mm
Net Weight 4.4 kg (Battery included)
Gross Weight 6 kg
* Vales referred to the unit connected to mains.
Our products are subject to change. Modications to technical features remain subject to change without notice.
