SYSTEM PROGRAMMING - Menu 1
INSTALL MANUAL
DIAGNOSTICS
AL.1
ALARM STATUS / DIAGNOSTICS
ALARM STATUS / DIAGNOSTICS
LED FLASHES OUTPUT DIAGNOSTICS
2 LOCK OUTPUT OVERLOAD
3 UNLOCK OUTPUT OVERLOAD
4 TRUNK OUTPUT OVERLOAD
5 STARTER DISABLE OVERLOAD
6 NOT USED
7 AUX 5 OUTPUT OVERLOAD
8 2ND UNLOCK OUTPUT OVERLOAD
If the alarm system is triggered, the system will retain in memory the cause of the
trigger. When disarming the alarm, the siren will chirp 3 times to indicate the alarm
had been triggered. The system’s LED will also flash in pulses to indicate which input
triggered the alarm.
*LED status will be cleared when the ignition is turned ON. For proper memory
clearing, insure to connect the alarm ignition input to the ignition on the vehicle.
If an output from the alarm is shorted the siren will chirp 4 times and the park lights
will flash 4 times when the system is armed or disarmed. The LED will flash a
diagnostic code that represents the circuit that is at fault. (See Chart Below). Turning
the ignition to the on then off position will reset the diagnostic code.
SIREN CHIRPS LED FLASHES DIAGNOSTICS / STATUS
3 2 SHOCK SENSOR TRIGGER
3 3 DOOR / HOOD TRIGGER
3 4 IGNITION TRIGGER
0 OFF SYSTEM DISARMED
0 ON SOLID SYSTEM IN VALET / SERVICE MODE
0 SINGLE FLASHES SYSTEM ARMED
0 RAPID FLASHES PASSIVE ARM COUNTDOWN
