MIN MAX
LEVEL
EGA900D / EGA1400D / EGA1700D
1.Speaker terminals
2. Input Sensitivity Adjustment
Controls & Functions
3. Low Level Input RCA jacks
SPEAKER
TOP
FRONT
LINE OUT
L-CH L-CH R-CHR-CH
INPUTS
EGA900D / EGA1400D / EGA1700D
EGA900D / EGA1400D / EGA1700D
CONTROLS & FUNCTIONS
5
This control adjusts the amplifier's input sensitivity. Input sensitivity is variable from 200 Millivolts to
8 volts. Clockwise increases sensitivity. Counterclockwise decreases sensitivity. The amplifier can
be driven to full power with a wide range of signal levels. A lower signal level will require
increased sensitivity for full power. A higher signal level will require decreased sensitivity.
Avoid setting sensitivity lower than necessary as this would introduce unwanted distortion.
These inputs are for signal cables from the source. Always use high quality shielded RCA cables.
